Arkon IPM127 User Manual

SM427 | Bicycle Handlebar Mount with Universal Holder IPM127 | Bicycle Handlebar Mount for Apple® iPhone™
GN032-SBH
Bicycle Handlebar
Mount
Bicycle Handlebar Mounting
Step 1. Choose a safe location on the handlebars of your bicycle in
which to mount the pedestal.
Step 2. Using a screwdriver, remove the two mounting screws (A)
in order to release the ball plate and swivel head (B) so the
mount can be placed around the handlebars.
Step 3. Wrap the rubber rings (C) around the handlebar and
reassemble the ball plate and swivel head (B) around the
rubber rings. Secure the mount assembly by using the
screwdriver to retighten the two mounting screws.
C
Safety Precautions
!
Do not reposition the pedestal while cycling or driving. Arkon
Resources, Inc. does not promote the adjustment of mobile devices
except when the bicycle or vehicle is safely parked or stopped.
Arkon is not responsible for any damages caused to your bicycle, your
device, or yourself due to the installation or use of this product.
Package Contents:
CC005-IP
(1) GN032-SBH - Bicycle handlebar mount
Custom Cradle
for iPhone (1) CC005-IP - Custom cradle for Apple iPhone
Compatible with:
• Apple iPhone 3G and Original iPhone
Apple brand name and iPhone product name are trademarks or registered
trademarks of Apple, Inc. Arkon Resources, Inc. is not affi liated with Apple, Inc.
Precaution: Arkon strongly recommends using a securing
!
strap to provide extra protection for your device. Failure to
do so may result in damage to your device. Do not operate
portable devices while riding. Arkon Resources, Inc. assumes
no liability for safety of bicycle rider or portable device.
Connect iPhone Cradle to Pedestal and iPhone Insertion
Step 1. Connect the dual T-slots (C) on iPhone cradle to the dual
T-tabs (D) on the bicycle pedestal head. Adjust the angle
and rotation of the pedestal head by tightening the swivel
tightening ring (E).
A
B
Step 2. Lift and hold the upper thumb tab (F) while gently lowering
the iPhone device (not included, sold separately) into the
custom cradle.
B
Consumer Hotline:
USA (800) 841-0884
INT'L (626) 254-9005
Monday - Friday 9 am - 5 pm, PST
E
D
F
(iPhone device
not included)
®
The Mobile Mounting Specialists™
Arcadia, CA 91006 USA
Designed in USA | Made in Taiwan
© Copyright 2010 Arkon Resources, Inc.
C
