1.1 Replacement Parts

1
4
5
Replacement Parts
Item Category Part No.
1 Operator
WL-PA03
W7-150
2 Control Board
W7-130-1 HA Digital Control Board
W5-421
3 Fuse
W5-422
W7-200
W7-205
4 Push Arm
W5-502C
w5-502B
W5-500C
W5-500B
W5-506C
W5-505C
W5-506B
W5-505B
Z-Arm
5
(Pull)
W5-508C
W5-507C
W5-508B
W5-507B
Description
LP Operator (Non-Handed)
Analog Control Board
Fuse 3AMP Analog Board
Fuse 3AMP Digital Board
Complete Push Arm-Clear
(with 17.5" rod)
Complete Push Arm-Bronze
(with 17.5" rod)
Cast portion - Clear
Cast portion - Bronze
Extended Rod 22"- Clear
Extended Rod 22"- Clear
Z-Arm RH - Clear
Z-Arm LH - Clear
Z-Arm RH - Bronze
Z-Arm LH - Bronze
Extended Z-Arm RH - Clear
Extended Z-Arm LH - Clear
Extended Z-Arm RH - Black
Extended Z-Arm LH - Black
Entrematic Canada Inc.
Toll Free: 1-877-348-6837
info.ditec.ca@entrematic.com
www.ditecentrematic.ca
1.0 BEFORE INSTALLATION
3
6
b
6
a
8
7
Replacement Parts
Item Category
Pull Arm Track
6a
- Short
(for Z-arm)
Pull Arm Track
- Long
6b
(for Universal Arm/
Center Spindle)
7 Universal Arm
Centre Spindle
8
Arm
9 Rocker Switch
10 Power Supply Kit
Entrematic USA Inc.
Toll Free: 1-866-901-4284
info.ditec.us@entrematic.com
www.ditecentrematic.us
2
9
HOLD OPEN
OFF
AUTOMATIC
10
Part No. Description
W5-550 Pull Track Assembly - Clear
W5-555 Pull Track Assembly - Bronze
Pull Track Assembly Long
W5-551
- Clear
Pull Track Assembly Long
W5-556
- Bronze
W5-512C Universal Arm - Clear
W5-512B Universal Arm - Bronze
W5-510C Center Spindle RH - Clear
W5-511C Center Spindle LH - Clear
W5-510B Center Spindle RH - Bronze
W5-511B Center Spindle LH - Bronze
WL-
ON/ OFF/ HOLD OPEN
Rocker
3 position switch
Switch
WL- RS-25-24
PWRKIT Power Supply Kit
HA8-LP Manual V. 4.0
Pg. 6
