Radio Systems Millenium-D Digital Console
5.3.2.3

Console interconnection

Interconnect the SPKR, GRND and AUX in pins from the appropriate intercom card outputs on the two consoles, or to
talk-back Audio Connectors J36 & J37 on consoles with no intercom board.
5.4

Calibration

Adjust the output level control on the intercom card for more level at the remote speakers or console.
Adjust the external cue level control on the analog output board to set the intercom input level and to balance it with the
cue level of the internal console cue inputs.
Page 44
