Radio Systems Millenium-D Digital Console
4.6.2

VU Meter "0" Calibration

The console was calibrated at the factory for an output level of +4dBv, into 600 ohms, when the VU meters indicate "0".
To calibrate the VU meter "0" indication:
4.6.3

Peak LED Trip Point Calibration

The console was calibrated at the factory for an output level of +4dBv, into 600 ohms, when the VU meters indicate "0",
and for a peak LED trip point of +2VU. To perform Peak LED Trip Point Calibration:
Note: Six channel consoles share the same meters for PROGRAM.1 and PROGRAM.2 monitoring. The front panel VU
meter switch selects the signal to be displayed. Adjustment must be made with both switch settings.
4.6.4

External Monitor Input Level

There is a separate adjustment, located on the Output Board for each of the four stereo external inputs.
4.6.5

Cue Bus External Input Level

The level adjustment for the external cue buss input is located on the Output Board.
1. Perform output level calibration as detailed previously.
2. Adjust the VU meter calibrate trimmers, located on the Output Board for a "0" reading on
each meter.
1. Perform output level calibration as detailed previously.
2. Perform VU meter "0" calibration as detailed previously.
3. Adjust oscillator to the desired peak LED trip point level (typically 0 to 3dB hotter).
4. Adjust the peak LED trip point trimmers to that the LEDs just illuminate.
1. Connect a high impedance voltmeter to the unmuted monitor output.
2. Select a high level input, and reproduce the nominal level from a test tape, record or CD.
3. Turn the mixing channel "on", select the program mix bus, and adjust the fader for "0" VU.
4. Depress the "program" monitor input switch.
5. Note the reading on the voltmeter.
6. Feed the nominal input level to any external input and select that monitor input switch.
7. Adjust the associated external input level trimmer until the voltmeter gives the same indication
as in step 5.
8. Repeat steps 6 and 7 for all external inputs.
1. Connect a high impedance voltmeter to the external cue speaker
terminals.
2. Select a high level input, and reproduce the nominal level from a test tape, record or CD.
3. Place the mixing channel into "cue", and adjust the cue level control VR2 for normal listening
level.
4. Note the reading on the voltmeter.
5. Feed the nominal input level into the external cue input.
6. Adjust the external cue input level trimmer until the voltmeter gives the same indication as in
step 4.
Page 30
