2.2.3 Remote Control Options – by Input
2.2.3.1 Pulse/Holding Remote Control
Insertion of these jumpers determine whether the remote control pins on the remote control connector pulse to ground
when the channel is turned on, or remain at ground potential for the duration of the channel on state.
Pulse mode is generally used for PC and CD player control. Holding mode is generally selected for skimmer and other
units that require on/off control.
2.2.3.2 Send Through of Remote On/Off Commands
Installation of these option jumpers will cause channel on/off commands that were initiated remotely (i.e. sent to the
channel via remote connector pins 1, 2, 5, or 12) to, in turn, create remote on/off output pulses (i.e. send remote control
commands to external equipment via remote connector pins 3, 4, 7, or 11). Normally, you would not want these remote
channel commands to be "sent through", thereby creating a new command and potentially retriggering the remote de-
vice via a false echo of the original command. This situation would apply when a remote device is wired to both control
and be controlled by an input channel; typically the case with a digital storage system that is wired to be both remotely
started by the channel, and turn off the console channel at the end of the audio cut.
2.2.4 Muting Buses
Two muting buses, referred to as mute 1 and mute 2, perform the following functions:
Mute Bus 1 – mutes the cue speaker, dims monitor send #1, pulls mute 1 terminal 5 to ground on Output Board connector J7.
Mute Bus 2 – mutes monitor send #2, pulls mute 2 terminal 4 to ground on Output Board connector J7.
2.2.5 Timer Reset
Inserting timer reset jumpers activates of the timer reset bus in conjunction with a selected input. The bus will go low
momentarily (100 ms) when the mixing channel is first placed into the "On" mode. Depressing the "On" button after the
channel is already turned "On" will result in another pulse of the bus.
Insert jumper H for input A – holding mode.
Default is no jumper; pulse mode.
Insert jumper C for input B – holding mode.
Default is no jumper; pulse mode.
Insert jumper D to enable send through in input A.
Default is no jumper; no send through.
Insert jumper B to enable send through in input B.
Default is no jumper; no send through.
Insert jumper T for input A to mute bus 1.
Default is no jumper; no mute.
Insert jumper P for input A to mute bus 2.
Default is no jumper; no mute
Insert jumper V for input B to mute bus 1.
Default is no jumper; no mute
Insert jumper R for input B to mute bus 2.
Default is no jumper; no mute
Insert jumper S for input A to reset the timer.
Default is no jumper; no timer reset.
Insert jumper V for input B to reset the timer.
Default is no jumper; no timer reset.
Page 13
See Illustration B-1, Pg16
