INSTRUCTION MANUAL
18v CORDLESS
LITHIUM-ION
TILLER
MODEL NO: TH18VT -- PRODUCT NO: 1938207001
EN - ORIGINAL INSTRUCTIONS
ASSEMBLY REQUIRED
SAVE THESE INSTRUCTIONS
SPARES & SUPPORT: 01793 333212
BATTERY MUST BE FULLY CHARGED BEFORE FIRST USE
FOR YOUR SAFETY
Please read & understand this manual, paying attention to the safety instructions, before use.
Incorrect use of the product could put the operator or machine in danger.
Whilst every effort has been made to ensure the accuracy of information contained in this manual, our
policy of continuous improvement determines the right to make modifications without prior warning.
Images used are for illustration purposes only
V1 24-04-2019
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for The Handy TH18VT
Summary of Contents for The Handy TH18VT
- Page 1 INSTRUCTION MANUAL 18v CORDLESS LITHIUM-ION TILLER MODEL NO: TH18VT -- PRODUCT NO: 1938207001 EN - ORIGINAL INSTRUCTIONS ASSEMBLY REQUIRED SAVE THESE INSTRUCTIONS SPARES & SUPPORT: 01793 333212 BATTERY MUST BE FULLY CHARGED BEFORE FIRST USE FOR YOUR SAFETY Please read & understand this manual, paying attention to the safety instructions, before use.
- Page 2 Copyright Notice Copyright © Handy Distribution Permission is granted to reproduce this publication for personal & educational use only. Commercial copying, redistribution, hiring or lending is prohibited. No part of this publication may be stored in a retrieval system or transmitted in any other form or means without written permission from Handy Distribution.
-
Page 3: Table Of Contents
CONTENTS SPECIFICATION IMPORTANT INFORMATION GENERAL SAFETY INSTRUCTIONS KNOW YOUR MACHINE COMPONENTS ASSEMBLY OPERATION BATTERY & CHARGER MAINTENANCE TROUBLE SHOOTING PARTS DIAGRAM & LIST DECLARATION OF CONFORMITY WARRANTY ASSEMBLY IS REQUIRED This product requires assembly before use. See the “Assembly” section for instructions. Please check that all parts required for the assembly of this spreader are included. -
Page 4: Specification
SPECIFICATIONS The manufacturer reserves the right to change the product specification and livery according to continued product improvements. Model TH18VT Product Number 1938207001 Weight N.W 4.36kg Voltage 18v (Max 20v) Battery 2.0Ah Charging Time Up to 90 mins Run Time... -
Page 5: General Safety Instructions
GENERAL SAFETY INSTRUCTIONS It is important that you read and understand the owner’s manual and labels affixed to the machine. Learn its application and limitations as well as the specific potential hazards. Retain these instructions for future reference. The operator is responsible for following the warnings & instructions in this manual and on the product. - Page 6 IMPORTANT SAFETY WARNINGS TO REDUCE RISK OF INJURY: Before any use be sure everyone using this product reads and understands all safety instructions and other information contained in this manual. CAUTION: Wear appropriate personal hearing protection during use. Under some conditions and duration of use, noise from this product may contribute to hearing loss.
- Page 7 DO NOT OVERREACH Keep proper footing and balance at all times when using the machine. Use on slopes with great care. Never stand on the machine. Serious injury could occur if the machine is tipped or if the moving parts are unintentionally contacted.
-
Page 8: Know Your Machine
KNOW YOUR MACHINE Trigger Safety Button Front Handle Upper Shaft Wing Nut Fixing Lower Shaft Side Cover Motor Housing Tine 1 (Right) Tine 2 (Left) 18v 2Ah Battery Battery Charger... -
Page 9: Components
COMPONENTS This product must be assembled correctly before use. Carefully remove the product and any accessories from the carton. Make sure all items listed below are included. If you require assistance with regards to the contents or operation of the machine, please contact us: TEL: 01793 333212 EMAIL: customerservice@handydistribution.co.uk (MON –... -
Page 10: Assembly
ASSEMBLY UPPER & LOWER SHAFT (FIG. 3A) Slide the lower handle section into the upper handle section. Line up the holes on each tube, and make sure the cable is clear of the mounting holes. Secure the two sections together with the M6x45 carriage bolt and wing nut. LOWER SHAFT AND MOTOR (FIG. - Page 11 WARNING: When connecting the tilling head and lower handle using the two self-tapping screws supplied, make sure the screws are securely tightened. Screw heads should be recessed below the surface. DO NOT START THE UNIT UNTIL TILLING HEAD AND LOWER HANDLE ARE SECURELY CONNECTED. Once the tilling head and lower handle are securely connected, do not remove the self-tapping screws or attempt to disassemble for any purpose.
-
Page 12: Operation
OPERATION THE BATTERY MUST BE FULLY CHARGED BEFORE THE FIRST USE OF THE PRODUCT. SEE STARTING & STOPPING WARNING The tines start rotating immediately after the tiller is switched on. Keep hands and feet away from the tines. To switch ON, hold the tiller firmly with two hands. One hand should be placed on the top trigger hand, with your other hand firmly holding the front handle. - Page 13 For preparing seed beds, we recommend using one of these tilling patterns: Tilling Pattern A – Make two passes over area to be tilled, the second at a right angle to the first. Tilling Pattern B – Make two passes over area to be tilled, the second overlapping the first. Clearing foreign objects: During operation a stone or root could become lodged in the tines, or tall grass or weeds may become wrapped around the tine shaft.
-
Page 14: Battery & Charger
BATTERY & CHARGER By pressing the button on the battery, the LED display will show the battery capacity. LED LIGHTS BATTERY STATUS LED x4 Battery is 75-100% charged LED x3 Battery is 50-75% charged LED x2 Battery is 25-50% charged LED x1 Battery is 0-25% charged BATTERY CHARGER... -
Page 15: Maintenance
MAINTENANCE WARNING Before carrying out maintenance operations, disconnect power supply (Remove Battery). Before each use check the extension cord for signs of damage or ageing. Replace the cable if it is cracked, split or otherwise damaged. Check the condition of the tines and ensure that all threaded connections are securely tightened. -
Page 16: Trouble Shooting
2. Install the tines with hub onto the shaft. Ensure the larger diameter whole of the hub is facing outward. The left and right tine assemblies must be installed symmetrically (Fig. 8). 3. Install the end caps. 4. Install the M8x170 bolt. Secure the assembly by tightening the M8 hex locknut with a hex head wrench. 5. - Page 17 PARTS DIAGRAM – TH18VT (1938207001) NOTE: Parts Lists are supplied for information purposes only, not all parts are stocked individually & we recommend you contact our Spares Team on 01793 333212 for expert advice...
- Page 18 PARTS LIST – TH18VT (1938207001) HANDY PART NO. DESCRIPTION TH250-181018012200 Left Adapter TH250-182018201200 Left Handle TH18B2 18v Battery TH250-182018204200 Safety TH250-232018212020 Safety Button Spring TH250-152018215000 Micro-Switch TH250-182018202200 Right Handle TH250-181018011200 Right Adapter TH250-120427163514 Screw ST3.5x14 TH250-120427163519 Screw ST3.5x19 TH250-182838287200 Plug-In Seat...
- Page 19 PARTS LIST – TH18VT (1938207001) HANDY PART NO. DESCRIPTION TH250-202818101000 Worm Deep Groove Ball Bearings TH250-120101082208 TH250-182818224000 608 Bearing Housing TH250-182818223000 Case Cover TH250-182818221000 Left Motor Housing TH250-182818206000 Pin Holder TH250-202203201000 Female Insert TH250-182818207000 Pin Cover TH250-120421223014 Screw ST3x14 TH250-182818222000...
- Page 20 EC DECLARATION OF CONFORMITY We Handy Distribution Ltd - SN3 5HY (Importer) declare that the product: Designation: 18v Cordless Lithium-Ion Tiller Model(s): TH18VT Product Number: 1938207001 Idle Speed: 160rpm Protection: IPX1 Voltage: 18v d.c Battery: 2Ah Type/Serial No. As per rating label on machine...
- Page 21 GJ HANDY & CO LTD USER WARRANTY POLICY Users Statement of Warranty Each new machine is warranted against defective material or assembly of material under normal usage. The warranty applies to the original purchaser and covers faulty parts and the labour involved in replacing and repairing those parts, which are of original manufacture.
- Page 22 Disclaimer a) This warranty is only a remedy for defect of products. GJ Handy & Co Ltd will never warranty in terms of the merchantability or the fitness for a particular purpose. b) No person is authorised to make any warranties, representations or promises, expressed or implied, on behalf of GJ Handy &...
-
Page 24: Tel: 01793 333212
For spares or support of your handy product, please contact us: Tel: 01793 333212 Email: customerservice@handydistribution.co.uk (Mon – Fri 8.00am to 5.30pm excl. Bank Holidays) To see our range of garden machinery & equipment visit: www.thehandy.co.uk Making gardening easier & affordable since 1938 Distributed by Handy Distribution, Murdock Road, Dorcan, Swindon, SN3 5HY...
