INSTRUCTION MANUAL
800W ELECTRIC
TILLER
Model No: THET -- Product No: 193874002
ASSEMBLY REQUIRED
SAVE THESE INSTRUCTIONS
SPARES & SUPPORT: 01793 333212
IMPORTANT
Please read & understand this manual, paying attention to the safety instructions, before use.
The manufacturer reserves the right to change the product specification and livery according to
continued product improvements.
Images used are for illustration purposes only

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the THET 193874002 and is the answer not in the manual?

Questions and answers

Related Manuals for The Handy THET 193874002

Summary of Contents for The Handy THET 193874002

  • Page 1 INSTRUCTION MANUAL 800W ELECTRIC TILLER Model No: THET -- Product No: 193874002 ASSEMBLY REQUIRED SAVE THESE INSTRUCTIONS SPARES & SUPPORT: 01793 333212 IMPORTANT Please read & understand this manual, paying attention to the safety instructions, before use. The manufacturer reserves the right to change the product specification and livery according to continued product improvements.

  • Page 3: Table Of Contents

    CONTENTS SPECIFICATION IMPORTANT INFORMATION GENERAL SAFETY INSTRUCTIONS COMPONENTS ASSEMBLY OPERATION MAINTENANCE TROUBLE SHOOTING PARTS DIAGRAMS & LISTS WARRANTY EC DECLARATION OF CONFORMITY ASSEMBLY IS REQUIRED This product requires assembly before use. See the “Assembly” section for instructions. Please check that all parts required for the assembly of this spreader are included. If for any reason you believe a part for the assembly is missing or damaged, please contact us.

  • Page 4: Specification

    SPECIFICATION The manufacturer reserves the right to change the product specification and livery according to continued product improvements. Model THET Product Number 193874002 Motor 230v, 50Hz, 800W Idle Speed 400rpm Tilling Width 30cm Tilling Depth 20cm Noise Pressure Level (L 73.6dB(A) Guaranteed Noise Power Level (L 93.0 dB(A)
  • Page 5 DRESS PROPERLY Do not wear loose clothing, gloves, scarfs, neckties or jewelry (rings, wrist watches), which can be caught in moving parts. Protective electrically non-conductive gloves and non-skid heavy duty footwear are highly recommended when working. Wear a face or dust mask if the operation is dusty. Always wear safety glasses/goggles and/or face shields.
  • Page 6 PROTECT THE ENVIRONMENT Take left over materials to an authorised collection point or follow the stipulations in the country where the mixer is used. Do not discharge into drains, soil or water. STORE IDLE EQUIPMENT When not in use, the machine should be stored in a dry location. Keep the machine away from children and others not qualified to use it.

  • Page 7: Components

    COMPONENTS Trigger Lever Safety Switch Cable Relief Upper Handle Carrying Handle Lower Handle Fender Protective Shield Tines...

  • Page 8: Assembly

    ASSEMBLY Before commencing assembly, unpack the contents of the box and check that nothing is damaged. You will require a Phillips (crosshead) screwdriver and an 8mm spanner. HANDLEBARS  Remove the two black crosshead screws from the Trigger switchbox. Remove the small switchbox housing.

  • Page 9: Operation

    OPERATION Move the tiller to the work area before starting the motor. GEARBOX LUBRICATION Grease is supplied in the machines gearbox at the factory. High quality automotive grease should be applied to the gearbox every 2 years. The gearbox holds a maximum of 60ml of grease. Regularly check for leaks coming from the gearbox.

  • Page 10: Maintenance

    USING THE MACHINE  Hold the tiller firmly when switching on as it may jump when the tines start rotating.  The tines will pull the tiller forward during operation – press down on the handle to dig the tines into the soil.
  • Page 11 STORAGE The tiller should be stored in a dry area, out of the reach of children. At the end of the season, or the tiller is not going to be used for some time:  Clean the tiller.  Wipe over the metal surfaces with an oil-impregnated cloth to protect them from corrosion (non-resinous oil) or spray a fine coat of oil onto them from a can.

  • Page 12: Trouble Shooting

    TROUBLE SHOOTING ISSUE LIKELY CAUSE SOLUTION No Electricity Check mains connection Defective Cable Check cable, replace if necessary or repair if possible. Should only be carried out by electrical specialist. Defective safety switch or plug Arrange for inspection by electrical or garden machinery Motor does not start specialist.
  • Page 13 PARTS DIAGRAM - MACHINE NOTE: Parts Lists are supplied for information purposes only, not all parts are stocked individually & we recommend you contact our Spares Team on 01793 333212 for expert advice.

  • Page 14: Parts List

    PARTS LIST Part No. Description Part No. Description TH165-1 Bearing 608Z TH165-26 Nut M8 TH165-2 Worm Shaft TH165-27 Ring TH165-3 Bearing 6200 TH165-28 Gearbox Case Right TH165-4 Coupler TH165-29 Rubber Seal TH165-5 Rubber Seal 2 TH165-30 Oil Bearing TH165-6 Flexible Shaft TH165-31 Seal TH165-7...
  • Page 15 WIRING DIAGRAM...
  • Page 16 GJ HANDY & CO LTD USER WARRANTY POLICY Users Statement of Warranty Each new machine is warranted against defective material or assembly of material under normal usage. The warranty applies to the original purchaser and covers faulty parts and the labour involved in replacing and repairing those parts, which are of original manufacture.
  • Page 17 GJ HANDY & CO LTD USER WARRANTY POLICY Not covered by this warranty a) The warranty policy does not cover any depreciation or damages caused by ordinary wear, rusting or corrosion, lack of correct maintenance or operation, misuse, abuse, lack of transportation or accident.

  • Page 18: Ec Declaration Of Conformity

    EC DECLARATION OF CONFORMITY We Handy Distribution Ltd - SN3 5HY (Importer) declare that the product: Designation: 800watt Electric Tiller Model(s): THET-A Product Number: 193874002 Type/Serial No. As per rating label on machine Complies with the following directives: 2006/42/EC - Machinery Directive Standards and technical specifications referred to: EN 55014-1:2006+A1+A2, EN 55014-2:1997+A1+A2, EN 61000-3-2:2006+A1+A2, EN 61000-3-3:2013, EN 60335-1:2012, EN 709:1997+A4, EN 62233:2008, ZEK 01.4-08/11.11...

  • Page 20: Tel: 01793 333212

    For spares or support of your handy product, please contact us: Tel: 01793 333212 (Mon – Fri 8.00am to 5.30pm excl. Bank Holidays) Email: customerservice@handydistribution.co.uk To see our range of garden machinery & equipment visit: www.thehandy.co.uk Making gardening easier & affordable since 1938 Distributed by Handy Distribution, Murdock Road, Dorcan, Swindon, SN3 5HY...
