TouchScreen User Guide
Each button is described in the following table:
Figure 2: TouchScreen Device & Home Screen
(missing or bad snippet)

Understanding the Screen

The TouchScreen communicates with your security system. It combines security and home controls on a
graphical interface, providing:
A real-time view of the system statuses
Tools to manage your security system
Additional optional applications such as news and weather
The first screen displayed is the Home screen. It is from this screen that you navigate through menus by
tapping buttons to access the function you desire. If the screen is black (showing nothing) this is because
the system is not receiving A/C power or the display is powered off to conserve battery life.
The screen is divided into the following operational sections:
Security Status Header (see page 17)
System & Zone Trouble Header (see page 18)
Content Area (see page 24)
16
