Tylo Sense Combi-U 7 Quick Start Manual

Connect NTC Sensor cable
to jack 1 on circuit board.
6 15 14
10
3 x 14 AWG
RJ10 4P4C
RJ10 4P4C
max 300 feet - Combi Pure
Figure 19: Wiring diagram
1. NTC Sensor - Combi Pure.
2. Ext switch (External switch Optional)
Door jumper pre-installed in terminal #3.
3.
(Door contact not required for N America)
4.-8. N/A
Pure Control
9.
10. Heater
11. Terminal for connection of electrical cable
12. Control panel (connect to position 9)
13. Sensor - Combi Pure (connect to NTC
terminal #1)
14. Light/terminal for connection of light.
(requires separate 120v supply)
15. Door Contact not required for N America
16. External switch (option)
2900 5262
SENSE COMBI PURE Quick-Start Tip Sheet
This page to be used in conjuction with Tylo Full Manual included
CONNECTION/WIRING DIAGRAM
TAB
Model Amperage
Sense Combi-U 7
Sense Combi-U 8
Note: Heating elements do not change for voltage changes. The heater output will change
based on the voltage applied to heater. Most North American homes are 240v.
1 2 3 4 5
6 7 8 9
Connect Control cable to
jack 9 on circuit board.
13
12
Field Connect three
* ** copper conectors
RJ10 4P4C
RJ10 4P4C
208 V 1 Phase
Output Wire Size
Amps kW AWG
26 5.3 10
30 6.3 8
11
5.3-8.3 kW
208/240 V~
x3
Sensor Installation Tip
Sensor with metal tab can usually installed without cov-
er with one screw through the sensor tab directly to the
If using Sensor Cover, you must feed the sensor wire
through the sensor holder FIRST before putting sensor
wire in the wall.
2018-01-02
240 V 1 Phase
Amperage Output Wire Size
Amps kW AWG
30 7.0
35 8.3
14
In order for control
G
to operate light, a
separate 120V supply
must be provided and
connected to heater
8
8
