4. Use a 24 inch (600 mm) length of stiff wire with a hook
formed on one end. Insert the hook end through the
slot between the bottom of the jar and the shipping
base (on the opposite side from the belt) and engage
one of the loop ends with the hook. See Figure 6.6.
5. Pull this loop end of the belt from under the
cell and out through the slot. Disengage
the wire hook from the loop and again
insert the hook through a different slot
between the bottom of the jar and the
shipping base. See Figure 6.7.
6. Engage the other belt loop with the wire
hook and pull it out through the slot on the
same
side. Adjust the belt
loop is even with the loops on the two free
ends. See Figure 6.8.
Page 16
www.enersys.com
LIFTING LARGE-SIZE CELL
until the middle
LIFTING LARGE-SIZE CELL
Publication No. US-FL-IOM-002 January 2007
LIFTING LARGE-SIZE CELL
Figure 6.6
Figure 6.7
Figure 6.8
