Installation, Operating and Servicing
Instructions
CONVECTOR
Electric Convection Ovens
CO133M, CO133T, CO223M, CO223T
CO235M, CO235T
Please make a note of your product details for
future use:
Date Purchased:_________________________
Model Number:__________________________
Serial Number:__________________________
Dealer:_________________________________
_______________________________________
IS 731 ECN 4421
Page 1 of 15
Advertisement
Table of Contents
Related Manuals for Lincat CO133M
Summary of Contents for Lincat CO133M
- Page 1 Installation, Operating and Servicing Instructions CONVECTOR Electric Convection Ovens CO133M, CO133T, CO223M, CO223T CO235M, CO235T Please make a note of your product details for future use: Date Purchased:_________________________ Model Number:__________________________ Serial Number:__________________________ Dealer:_________________________________ _______________________________________ IS 731 ECN 4421 Page 1 of 15...
-
Page 2: Table Of Contents
WARNING! This symbol is used whenever there is a risk of personal injury. CAUTION! This symbol is used whenever there is a risk of damaging your Lincat product. NOTE: This symbol is used to provide additional information, hints and tips. -
Page 3: Warnings And Precautions
During operation parts may become hot - avoid accidental contact. Disconnect this appliance before servicing, maintenance or cleaning. CHECK LIST OF ENCLOSURES Instructions Manual Shelves (2 off CO223M, CO223T). Shelves (3 off CO133M, CO133T, CO235M, CO235T). Water connection hose (CO133T, CO223T, CO235T). TECHNICAL DATA Tray Weight... - Page 4 ELECTRICAL CONNECTION VENT WATER CONNECTION WATER, ELECTRICAL CONNECTIONS RESET CO1xx VERSIONS ELECTRICAL WATER VENT CONNECTION CONNECTION WATER, ELECTRICAL CONNECTIONS RESET CO2xx VERSIONS IS 731 ECN 4421 Page 4 of 15...
-
Page 5: Installation And Commissioning
An air filter will need occasional access. (See Fig 3 for position). Fig 2 The water supply pressure must be from 2 - 6 bar (200kPa-600kPa). Lincat recommend that a water filter should be installed. Refer to Lincat’s website for the recommended option IS 731 ECN 4421... -
Page 6: Operating Instructions
OPERATING INSTRUCTIONS Only qualified or trained personnel should use this appliance. MODELS CO133M, CO223M and CO235M A- On/Off E- Fan Speed B- Power supply indicator F- 120 minute timer C- Oven heating indicator G- Reset D- Temperature control knob H- Filter Fig 3 Connect the appliance to the electricity supply. - Page 7 Note: When the door is opened, if the fan is set to fast speed, the fan will switch from fast to slow speed and return to fast speed when the door is closed. To turn the unit off set the temperature control knob to the off position and switch off at the mains.
- Page 8 How to programme your Touch screen Convector (COxxxT models). Home screen This is where you run recipes from (just press the recipe you want). You can switch into the oven mode from here. Pressing recipe manager takes you into the programming area Home Oven mode Recipe...
- Page 9 Recipe summary and edit screen This is where you view your recipe with changes highlighted in green. Press on the steps to edit them. Press on the name bar to rename the recipe. Attach or change an icon from the library. Click on to save to keep your recipe.
-
Page 10: Fault Finding
If when turning the unit on it fails to operate firstly check the power supply to the unit then the reset before contacting Lincat service. To re-set the safety thermostat, firmly push the red button which is recessed under the front edge of the unit see (Fig 3 –... -
Page 11: Cleaning
Your product has a manufacturer’s warranty. This requires you maintain and care for your product and follow maintenance instructions. If you fail to maintain your unit or damage components Lincat may charge you for a warranty repair. Please check the website for terms and conditions. - Page 12 Door inner glass removal and refitting With the door open, hold the lower edge of the inner glass and one of the metal tabs at the top. Carefully pull the glass towards you whilst lifting the metal tab. With the glass now free at the top, lift the glass panel clear. To refit, position onto the locating pins on the lower edge and close against the upper locating pins.
-
Page 13: Spare Parts List
SPARE PARTS LIST You can search for your spare parts on Lincat.co.uk using your products serial number. Part Number Description Used on CA208 Run Capacitor All Models CO215 Contactor CO235M, CO235T EL332 3.0 Kw Element CO133M, CO133T, CO223M, CO223T EL330 4.5 Kw element... -
Page 14: Accessories
CO223T, CO235T ACIK04 Standard filter kit, 1500 litre life CO133T, CO223T, CO235T SERVICE INFORMATION For help with the installation, maintenance and use of your Lincat equipment, please contact our service department: IS 731 ECN 4421 Page 14 of 15... -
Page 15: Service Information And Guarantee
• Product code All available on serial plate • Type number • Serial number Lincat reserve the right to carry out any work under warranty, given reasonable access to the appliance, during normal working hours, Monday to Friday, 08:30 to 17:00. GUARANTEE This unit carries a comprehensive UK mainland 2 year warranty.
