„SNACK"
132260
Gebrauchsanleitung
Elektro-Nudelkocher
D/A/CH
Seite 1 bis 16
Instruction manual
Electric pasta cooker
GB/UK
from page 17 to 32
Mode d'emploi
Cuiseur à pâtes électrique
F/B/CH
de page 33 à page 48
Manuale di utilizzo
Cuocipasta elettrico
I/CH
pagine da 49 a 64
Instrucciones de uso
Cocedor de pasta eléctrico
E
de la página 65 a la 80
V2/0715
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Bartscher SNACK
Summary of Contents for Bartscher SNACK
- Page 1 „SNACK“ 132260 Gebrauchsanleitung Elektro-Nudelkocher D/A/CH Seite 1 bis 16 Instruction manual Electric pasta cooker GB/UK from page 17 to 32 Mode d’emploi Cuiseur à pâtes électrique F/B/CH de page 33 à page 48 Manuale di utilizzo Cuocipasta elettrico I/CH pagine da 49 a 64 Instrucciones de uso Cocedor de pasta eléctrico...
-
Page 2: Table Of Contents
5. Installation and operation ..................27 5.1 Installation ......................27 5.2 Operation ......................28 6. Cleaning and descaling ..................30 7. Possible Malfunctions .................... 31 8. Waste disposal ......................32 Bartscher GmbH Franz-Kleine-Str. 28 D-33154 Salzkotten phone: +49 (0) 5258 971-0 Germany fax:... -
Page 3: Safety
Read this instruction manual before using and keep them available at all times! This instruction manual contains information about the installation, operation and maintenance of the device and should be consulted as an important source of information and reference guide. Awareness of the safety instructions and instructions for use in this manual will ensure the safe and correct use of the device. - Page 4 • Do not use any accessory or spare parts that have not been recommended by the manufacturer. These can be dangerous for the user or lead to damages of the device or personal injury, and further, the warranty expires. • To prevent hazards and to ensure optimum efficiency, no modifications or alterations to the device that are not explicitly approved by the manufacturer may be undertaken.
-
Page 5: Key To Symbols
1.2 Key to symbols In this manual, symbols are used to highlight important safety instructions and any advice relating to the device. The instructions should be followed very carefully to avoid any risk of accident, personal injury or material damage. WARNING! This symbol highlights hazards which could lead to injury. - Page 6 Never carry or lift the device by the supply cable. Always use the device handles. In any case do not open the device housing. In case of electrical or mechanical modifications the electric shock hazard will occur. Never immerse the plug in water or other liquids. Do not use any acid agents and make sure no water ingresses the device.
-
Page 7: Proper Use
Never touch the basin during the operation and directly afterwards. Hot water may burn arms, hands or fingers! Make sure that the water is cool by placing your hands 2 to 5 cm above the basin! CAUTION! In order to avoid any damages of the device follow the instructions below. Never switch the device on without water in the basin. -
Page 8: General Information
2. General information 2.1 Liability and Warrantees All the information and instructions in this manual take into account standard safety regulations, current levels of technical engineering as well as the expertise and experience we have developed over the years. The instruction manual was translated with all due care and attention. However, we do not accept liability for any translation errors. -
Page 9: Transport, Packaging And Storage
3. Transport, packaging and storage 3.1 Delivery check Please check the delivery upon completeness and transport damage immediately after receipt. In case of visible damage do not accept or accept the delivery with reservation only. Note the extent of damage on the carrier’s bill of delivery. Trigger off the complaint. Hidden damages should be reclaimed immediately after notice, as claims for damages can only be asserted within the effective period for complaints. -
Page 10: Technical Data
4. Technical data 4.1 Overview of parts Control elements Handle Housing Circuit box Heating element shield ON/OFF switch Control panel Basket Standby light (green) Lowered handles at the basin Function light (orange) Basin Temperature dial - 25 -... -
Page 11: Technical Specification
4.2 Technical specification Name Electric pasta cooker "SNACK" 132260 Code-no.: Material: stainless steel Power: 3.4 kW / 230 V~ 50 Hz Temperature range: up to 110° C Basin dimensions: W 240 x D 300 x H 200 mm Basin capacity:... -
Page 12: Installation And Operation
5. Installation and operation 5.1 Installation Positioning • Unpack the device and remove all packing material. Remove the protective film from the device. CAUTION! Never remove the rating plate and any warning signs from the device. • Place the device on top of an even, stable, dry, and water-resistant surface which supports the weight of the device and is not heat sensitive. -
Page 13: Operation
5.2 Operation Before first use • Clean the device before first use in accordance with the instructions in 6 "Cleaning and descaling". • Fill the basin up to the top with water and add a cleaning agent. Turn the device on and boil the water for several minutes. - Page 14 Preparing dishes NOTE! Put salt into heated water before placing the basket with pasta inside. • Place the desired food products into the basket. NOTE! Do not fill the baskets more than halfway, as the food contained may be over- or under-cooked.
-
Page 15: Cleaning And Descaling
RESET-button • After the device automatically shuts down to prevent overheating, it can only be reactivated by using the RESET button located at the bottom of the circuit box. • First, leave the device to cool, then remove the plastic cover over the RESET button by turning it counterclockwise, press the button, then turn the cover clockwise to replace it. -
Page 16: Possible Malfunctions
o Remove regularly the limestone deposits forming in the basin to avoid excessive energy consumption and reduced performance of the device. For this purpose use a solution of water with vinegar (3:1 ratio) or a commercially available descaling agent. Observe the instructions of manufacturers of such agents. o After descaling, rinse the basin with clean water a few times. -
Page 17: Waste Disposal
CAUTION! For the disposal of the device please consider and act according to the national and local rules and regulations. Bartscher GmbH Franz-Kleine-Str. 28 D-33154 Salzkotten phone: +49 (0) 5258 971-0 Germany...
