TeeJet Technologies MATRIX Installation Manual page 7

SYSTEM DESCRIPTION, CL230
Pos. Description
1 Berthoud TELEVOLUX Switch Box
2 CL230 Guidance Controller
3 BoomPilot cable (Sections)
4 BoomPilot cable (CANBUS & Power)
5 Section Driver Module
6 Power Cable, w/COBO connector
7 Berthoud ABSC Interface
8 Relay box
* Depending on CL230 Kit,
** Only kit no. 990-899 for 'OLD SAFI' & 'ARAG' valves
Connectors and fuses:
Pos. Description
A 4P connector, speed output
B 9P Connector (Data in/out, Sub.D. Female)
C Fuse (3A)
D 19P connector, from the Berthoud ABSC interface
E 19P connector, BoomPilot cable
F 4P Connector (CAN, Matrix and Section Driver Module)
G 2P Connector (Power to Matrix Controller)
H 2P connector, section power
I 35P Connector (Boom Section I/O to Section Driver Module)
J 14P connector, SDM module
K 2P Connector (System Power)
L Fuse (3A)
M 3P COBO connector
Part Number
-
* xxx-xxx
198-417
198-413
78-05072
45-05648
902-422
** 902-356
Part Number
166-603
39-00000
www.teejet.com
7
