TeeJet Technologies MATRIX Installation Manual page 3

REQUIRED PARTS AND KIT SELECTION
To add Automatically Boom Section Control to a Berthoud TELEVOLUX Switch Box, the following
part numbers are required:
MATRIX :
TM
Part no.
* xxx-xxx
** 990-898
** 990-899
45-05626
45-05648
* Refer to the MATRIX
TM
CL230:
Part no.
* xxx-xxx
** 990-898
** 990-899
* Refer to the CL230BP pricelist, ** 990-898 or 990-899
NEW SAFI
- 3 wire connection
- Permanent 12V and Gnd
- Switching input 12V = ON
Kit no. 990-898
Description
MATRIX Guidance controller kit
TM
Berthoud TELEVOLUX ABSC kit, for 'New Safi' or 'Pneumatic' valve type
(Pos. 4, 5, 6, 8 /System Overview)
Berthoud TELEVOLUX ABSC kit, for 'Old Safi' or 'ARAG' valve type
(Pos. 4, 5, 6, 8, 9 /System Overview)
Power/CAN/Data cable for MATRIX
Power Cable, w/COBO connector
pricelist, ** 990-898 or 990-899
Description
CL230 Guidance controller kit
Berthoud TELEVOLUX ABSC kit, for 'New Safi' or 'Pneumatic' valve type
(Pos. 3-6 /System Overview)
Berthoud TELEVOLUX ABSC kit, for 'Old Safi' or 'ARAG' valve type
(Pos. 3-5 /System Overview)
PNEUMATIC
- 2 wire connection
- Permanent Gnd
TM
(Pos. 2 /System Overview)
(Pos. 7 /System Overview)
OLD SAFI
- 3 wire connection
- Permanent Gnd
- 2 Switching input
1. 12V = ON
Kit no. 990-899
ARAG
- 2 wire connection
- Changeover polarity to
open and close
3
