LED'S ON THE SECTION DRIVER MODULE
Section Power:
I/O error:
CAN Data:
CAN Power:
14
www.teejet.com
ON when power is available for the section drivers.
Should normally be OFF
(Auto Mode: ON when automatic boom switching is active).
ON is flashing when it communicates with the CenterLine 230.
ON when power is applied to the CenterLine 230 and the SDM.
