Accessing the Green and Red Preset Banks

The C4 can store up to six presets (2 banks of 3 presets) accessible without a MIDI controller or the
Neuro Editor.
•
Green Preset Bank (Indicated by the green center LED): By default the center toggle switch
selects between three presets (Circle, Triangle, Square) stored in the first (green) bank of
presets.
•
Red Preset Bank (Indicated by the red center LED): Pressing the ALT button on the topside of
the pedal initiates a blinking pattern from the small LED on the pedal's face, indicating that the
second preset bank is accessible with the toggle switch. Upon moving the toggle switch the
center LED will turn red indicating the current preset is drawn from the second bank. Follow the
same process to switch back to the green bank.
Also, pressing and holding the footswitch from the bypassed state toggles between the first
(Green) and second (Red) preset banks. Note: if "Quick Bank Switch Using Footswitch" has been
selected from the Neuro Editor's "C4 Synth Hardware Options," it is also possible to change
preset banks with the footswitch while the pedal is still engaged.

Three Different Preset Modes

Connecting the C4 Synth to the Neuro Desktop or Neuro Mobile App (See the
info) allows you to select between three different Preset Modes: Standard (Default), Preset, and
WYSIWYG ("What You See Is What You Get"). To select which mode your C4 operates under, go the
C4's Hardware Options Menu (the C4 gear icon in the Connection section) and use the Preset /
WYSIWYG menu. Each mode is universal applies to all six presets available in the green and red
preset banks.
Standard (Default) Mode
In Standard Mode each preset engages with a pre-programmed preset, meaning the physical
positions of the knobs do not affect the sound of the preset. It is, however, possible to reach down
and make knob adjustments on the fly. If, after making a knob adjustment, the pedal is bypassed
then reengaged without moving the toggle switch, the sound will continue to reflect the new knob
positions. If the toggle switch is moved (regardless of whether the effect is engaged or engaged), the
pedal will revert to the parameter settings of the saved preset.
Preset Mode
Preset Mode works similar to the Standard (Default) Mode with one key difference, it allows you to
re-save the preset after making knob adjustments. So upon the initial engagement of a preset the
knob parameters will instantly jump to their saved values, regardless of the physical position of the
knobs. However, if you do make a knob adjustment, the center LED will start to blink, indicating that
edits have been made. After making an adjustment you can save the new settings by pressing and
holding the footswitch until the center LED stops blinking (around five seconds).
SA249 C4 Synth User Guide
Neuro Section for more
14
