- Page 1 ® INSTRUCTION MANUAL 7 Series Wrist Blood Pressure Monitor Model BP6350...
-
Page 2: Table Of Contents
Table of Contents Introduction ....................3 Important Safety Information ................5 1. Know Your Monitor ................9 2. Preparation ..................15 3. Using Your Monitor without a Smart Device ........21 4. Using Your Monitor with a Smart Device ..........24 5. Using Memory Function ...............27 6. -
Page 3: Introduction
Introduction Thank you for purchasing the OMRON BP6350 Wrist Blood Pressure Monitor. This blood pressure monitor is to be worn on your wrist. This monitor can be used by multiple users. This new blood pressure monitor uses the oscillometric method of blood pressure measurement. - Page 4 Contraindications • This monitor is contraindicated for use in ambulatory environments. • This monitor is contraindicated for use on aircraft.
-
Page 5: Important Safety Information
Important Safety Information Please read the Important Safety Information in this instruction manual before using this monitor. Please follow this instruction manual thoroughly for your safety. Please keep for future reference. For specific information about your own blood pressure, CONSULT WITH YOUR PHYSICIAN. Indicates a potentially hazardous situation which, if not Warning avoided, could result in death or serious injury. - Page 6 Data Transmission • This product emits radio frequencies (RF) in the 2.4 GHz band. DO NOT use this product in locations where RF is restricted, such as on an aircraft or in hospitals. Turn off the Bluetooth feature in this monitor and remove batteries when in RF restricted areas.
- Page 7 • Ensure that this monitor has acclimated to room temperature before taking a measurement. Taking a measurement after an extreme temperature change could lead to an inaccurate reading. OMRON recommends waiting for approximately 2 hours for the monitor to warm up or cool down when...
- Page 8 Battery Handling and Usage • DO NOT insert batteries with their polarities incorrectly aligned. • ONLY use 2 “AAA” alkaline batteries with this monitor. DO NOT use other types of batteries. DO NOT use new and used batteries together. DO NOT use different brands of batteries together.
-
Page 9: Know Your Monitor
1. Know Your Monitor Contents Monitor, 2 “AAA” alkaline batteries, storage case, instruction manual, quick start guide Monitor a. Wrist cuff (Wrist circumference 5.3" to 8.5" (13.5 cm to 21.5 cm)) b. Display c. [Memory] button d. [Date/Time setting] button e. - Page 10 Display and Symbols...
- Page 11 Date and time display Average value symbol Appears when viewing the average readings of the latest 2 or 3 readings taken within 10 minutes span. Memory symbol Appears when viewing readings stored in the memory. Systolic blood pressure reading Diastolic blood pressure reading Pulse display / Memory number Pulse rate appears after the measurement.
- Page 12 High symbol Appears if your systolic blood pressure is 130 mmHg or above and/or the diastolic blood pressure is 80 mmHg or above. Refer to section 1.4 for more information. Heart zone indicator Your monitor has a built-in heart zone indicator that is used as an aid in determining if the monitor is at the correct height.
- Page 13 Battery symbol (low) Flashes when batteries are low. Battery symbol (depleted) Appears when batteries are depleted. Bluetooth ON symbol Appears when Bluetooth is enabled. Bluetooth OFF symbol Appears when Bluetooth is disabled.
- Page 14 Classification of BP (Blood Pressure) ACC/AHA 2017 Hypertension guidelines define categories of BP in adults as below. Categories of BP in Adults* BP Category Systolic BP Diastolic BP Normal < 120 mmHg < 80 mmHg Elevated 120 - 129 mmHg and <...
-
Page 15: Preparation
2. Preparation Installing Batteries Push down the hook of the battery cover and pull downward. Insert 2 “AAA” alkaline batteries as indicated in the battery compartment. Close the battery cover. Note • When the “ ” symbol flashes on the display, it is recommended you replace batteries. - Page 16 • As soon as batteries are correctly installed, the year flashes on the display of your monitor. • The date and time will automatically be set when the monitor is paired with “OMRON connect US/CAN” app. Refer to section 4.1. Press the button once to adjust the year.
- Page 17 Press the [START/STOP] button to store the setting. It automatically turns off after 3 seconds. Note • If you need to reset the date and time, replace batteries or press and hold the button until the year flashes, and set the date and time as above steps. Blood Pressure Measurement Tips To help ensure an accurate reading, follow these directions: •...
- Page 18 • The blood pressure can differ between the right wrist and the left wrist, and the measured blood pressure values can be different. OMRON recommends to always use the same wrist for measurement. If the values between both wrists differ substantially, please check with your physician as to which wrist to use for your measurements.
- Page 19 Position the wrist cuff leaving a clearance of 0.5 inch (1 to 2 cm) between the cuff and the bottom of your palm. 0.5 inch (1 to 2cm) Wrap the wrist cuff firmly around your wrist. Do not apply over clothing.
- Page 20 Sitting Correctly To take a measurement, you need to be relaxed and comfortably seated in a room with a comfortable temperature. Place your elbow on the table to support your arm. • Sit in a chair with your legs uncrossed and your feet flat on the floor.
-
Page 21: Using Your Monitor Without A Smart Device
3. Using Your Monitor without a Smart Device Taking a Measurement You can use your monitor without pairing to a smart device. To pair your monitor with a smart device, refer to section 4.1. Note • To stop the measurement, press the [START/STOP] button once to deflate the wrist cuff. - Page 22 Monitor height Heart Zone Indicator Any locator bar (-) above the “ ” symbol Wrist is too high appears. Proper position The “ ” symbol lights in blue. Any locator bar (-) below the “ ” symbol Wrist is too low appears.
- Page 23 Remain still and do not move or talk until the entire measurement process is completed. As the cuff inflates, your monitor automatically determines your ideal inflation level. This monitor detects your blood pressure and pulse rate during inflation. The “ ”...
-
Page 24: Using Your Monitor With A Smart Device
Download and install the free “OMRON connect US/CAN” app onto your smart device. If you already have the “OMRON connect US/CAN” app and have created your account, open the app and add your new monitor. Open the app on your smart device and follow the instructions. - Page 25 • Please be aware that OMRON will not be responsible for the loss of data and/or information in the app. • “OMRON connect US/CAN” is the only app that we recommend to use with your monitor to transfer data correctly.
- Page 26 Disabling/Enabling Bluetooth Warning • This product emits radio frequencies (RF) in the 2.4 GHz band. DO NOT use this product in locations where RF is restricted, such as on an aircraft or in hospitals. Turn off the Bluetooth feature in this monitor and remove batteries when in RF restricted areas.
-
Page 27: Using Memory Function
5. Using Memory Function Your monitor automatically stores up to 90 readings. Note • This monitor can be used by multiple users. When you use memory function with other users, track (or manage) your own readings appropriately. Viewing the Readings Stored in Memory Press the button. - Page 28 Viewing the Average Reading Your monitor can calculate an average reading based on the latest 2 or 3 readings taken within 10 minutes span. When your monitor is off, press and hold the button for more than 2 seconds. Note •...
-
Page 29: Other Settings
6. Other Settings Disabling/Enabling Heart Zone Indicator The heart zone indicator is enabled as default. When your monitor is off, press and hold the button for more than 10 seconds. Note • Your monitor will automatically turn off after 3 seconds from the completion. •... - Page 30 Restoring Your Monitor to the Default Settings To delete all the information stored in your monitor, follow the instructions below. Make sure that your monitor is turned off. While holding the button down, press the [START/STOP] button within 2 seconds. Hold both buttons for more than 5 seconds.
-
Page 31: Error Messages And Troubleshooting
7. Error Messages and Troubleshooting In case of any of the below problems occur during measurement, first check that no other electrical device is within 12 inches (30 cm). If the problem persists, please refer to the table below. Display/Problem Possible Cause Solution Apply the wrist cuff correctly,... - Page 32 Refer to chapter 11. Follow the instructions shown in the “OMRON connect US/ The monitor cannot connect to CAN” app. If the “Err” symbol a smart device or transmit data still appears after checking the correctly.
- Page 33 Solution More than 70 readings are not transferred. Pair or transfer your readings This monitor is ready for to the “OMRON connect US/ flashes pairing or transferring your CAN” app so you can keep readings. them in memory in the app, and this error symbol disappears.
- Page 34 3. Follow the instructions shown in the smart device, or visit the Any other “Help” section in the “OMRON connect US/CAN” app for further communication help. issue occurs. If the problem still persists, contact customer service. Refer to chapter 11.
-
Page 35: Maintenance
8. Maintenance Maintenance To protect your monitor from damage, please follow the directions below: • Changes or modifications not approved by the manufacturer will void the user warranty. Caution • DO NOT disassemble or attempt to repair this monitor or other components. This may cause an inaccurate reading. -
Page 36: Specifications
9. Specifications Model BP6350 HEM-6231T-Z Display LCD digital display Cuff pressure range 0 to 299 mmHg Blood pressure measurement SYS: 60 to 260 mmHg range DIA: 40 to 215 mmHg Pulse measurement range 40 to 180 beats / min. Pressure: ±3 mmHg Accuracy Pulse: ±5% of display reading Inflation... - Page 37 Approximately 3.6" (w) × 2.5" (h) × 0.5" (l)* Dimensions (91 mm × 63 mm × 13 mm) (not including the wrist cuff) Measurable wrist 5.3" to 8.5" (13.5 to 21.5 cm) circumference Memory Stores up to 90 readings Monitor, storage case, 2 “AAA” alkaline batteries, Contents instruction manual, quick start guide Protection against electric...
- Page 38 Pictogram on the Product Indicates the correct positioning for the monitor on the wrist. About a wireless communication interference This product operates in an unlicensed ISM band at 2.4 GHz. In the event this Product is used near other wireless devices such as microwave and wireless LAN, which operate on the same frequency band as this Product, there is a possibility that interference may occur.
-
Page 39: Fcc Statement
10. FCC Statement FCC CAUTION Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 40: Limited Warranty
PURPOSE. IMPLIED WARRANTIES AND OTHER TERMS THAT MAY BE IMPOSED BY LAW, IF ANY, ARE LIMITED IN DURATION TO THE PERIOD OF THE ABOVE EXPRESS WARRANTY. OMRON SHALL NOT BE LIABLE FOR LOSS OF USE OR ANY OTHER SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT COSTS, EXPENSES OR DAMAGES. - Page 41 This warranty provides you with specific legal rights, and you may have other rights that vary by jurisdiction. Because of special local requirements, some of the above limitations and exclusions may not apply to you. FOR CUSTOMER SERVICE Visit our web site at: OmronHealthcare.com Call toll free: 1-800-634-4350...
-
Page 42: Guidance And Manufacturer's Declaration
Documents in the Scope of IEC60601-1-2:2014 Important information regarding Electro Magnetic Compatibility (EMC) BP6350 manufactured by OMRON HEALTHCARE Co., Ltd. conforms to IEC60601-1-2:2014 Electro Magnetic Compatibility (EMC) standard. Further documentation in accordance with this EMC standard is available at OmronHealthcare.com/... - Page 43 Bluetooth SIG, Inc. and any use of such marks by OMRON HEALTHCARE Co., Ltd. is under license. Other trademarks and trade names are those of their respective owners. App Store is a service mark of Apple Inc., registered in the U.S and other countries.
