Summary of Contents for Parker ERV Series
- Page 1 Bulletin PM-ERV-B/USA Maintenance Instruction & Parts List Revision Date: September 2005 Supersedes: April 2002 ERV Series Value Line Rodless Linear Actuator...
-
Page 2: Offer Of Sale
The products described herein, including without limitation, product features, specifications, designs, availability and pricing, are subject to change by Parker Hannifin Corporation and its subsidiaries at any time without notice. WARNING... - Page 3 Consult the factory or the Product Catalog for additional information. ERV Series Linear slides are electromechanical belt driven actuators. The mechanical capabilities and response of the units are greatly dependent on the entire drive train system including the motor or motor and gearbox combination.
-
Page 4: Exploded View
PM-ERV-B/USA Maintenance Instructions & Generic Parts List ERV Series Actuator Exploded View Carriage Assembly & Preload Adjustment When the actuators come from the factory the carriage wheels will be preloaded. If over the course of time the actuator becomes damaged or the preload is lost the wheels can be easily adjusted or if necessary replaced in the following manner. -
Page 5: Belt Tension
PM-ERV-B/USA Maintenance Instructions & Generic Parts List ERV Series Actuator Only after marking the cam locations should you remove a roller assembly. If a roller needs to be replaced or the preload needs to be adjusted, remove the wheel retainer screw in combination with the appropriate sized hex wrench. -
Page 6: Actuator Mounting
The mounting holes provided on the carriage as well as the T- slots are designed to accommodate standard Parker Hannifin IPS mounting brackets in the 28mm and 40mm profile sizes (ERV56 and ERV80 respectively). - Page 7 PM-ERV-B/USA Maintenance Instructions & Generic Parts List ERV Series Actuator Bumper Accessory External bumpers are available on these units for safety reasons or as emergency stops. These bumpers are designed as safety stops only and should not be used as end of stroke stops. Continuously using them as end of stroke stops may damage the drive train.
- Page 8 PM-ERV-B/USA Maintenance Instructions & Generic Parts List ERV Series Actuator Hall Effect Sensors Part Number Type LED Color Logic Cable/Connector SMHnn-1P N.O. Green SMHnn-1N N.O. 1.5M Cable SMCnn-1P N.C. Yellow With Leads SMCnn-1N N.C. White or Red SMHnn-1PC N.O. Green SMHnn-1NC N.O.
- Page 9 PM-ERV-B/USA Maintenance Instructions & Generic Parts List ERV Series Actuator Generic Part List ITEM # DESCRIPTION ERV56 ERV80 Carriage/Extended carriage ERV56R03(E) ERV80R03(E) Bearing retainer 12/24 ERV56R02 ERV80R02 Roller wheel assemblies 12/24 ERV56RCA ERV80RCA Wheel washer 12/24 WS-FHS-CM08 WS-FHS-CM12 Concentric roller cam...
- Page 10 ERV Series Actuator Offer Of Sale The items described in this document are hereby offered for sale at prices to be established by Parker Hannifin Corporation, its subsidiaries and its authorized distributors. This offer and its acceptance by any customer ("Buyer") shall be governed by all of the following Terms and Conditions.
- Page 11 PM-ERV-B/USA Maintenance Instructions & Generic Parts List ERV Series Actuator which may be assessed if the items are held to be exclusive liability and Buyer's sole and exclusive remedy taxable. for infringement of Intellectual Property Rights. 10. Indemnity For Infringement of Intellectual Property...
- Page 12 Parker Hannifin Corporation Actuator Division 135 Quadral Drive Wadsworth, Ohio 44281 USA Tel: (330) 336-3511 Fax: (330) 334-3335 Web Site: http://www.parker.com/automation...
