Install Dust Cap & Focus Ring
DUST CAP
FOCUS RING

Install Focus Ring

Focus Ring installation
Focus Ring find from packing accessory.
Install the Focus Ring into front lens area ( see the above figure).
Rotate the Focus Ring clockwise to fixing on main unit.

Install Dust Cap

If the unit don't used , install the Dust Cap on the Focus Ring
until to next time operation.
The double ring focus find from packing accessory.
5
