Aufbau der Datenblöcke
Datenstruktur
Alle Datenblöcke haben die gleiche Struktur:
Slave-
Funktions-
Adresse
code
1 Byte
1 Byte
Jeder Datenblock enthält vier Felder:
Slave-Adresse
Geräteadresse eines bestimmten Slaves
Funktionscode
Funktionsauswahl (Lesen, Schreiben von Worten)
Datenfeld
Enthält die Informationen:
- Wortadresse
- Wortanzahl
- Wortwert(e)
Checksumme
Erkennung von Übertragungsfehlern
2 Protokollbeschreibung
Datenfeld
Checksumme
CRC16
x Byte
2 Bytes
11
