4 Modbus addresses
Address Data type/
bit number
0x0024 INT
Bit 0
Bit 1
0x0025 INT
Bit 0 + Bit 8
Bit 1 + Bit 9
Bit 2 + Bit 10
Bit 3 + Bit 11
0x0026 FLOAT
0x0028 FLOAT
0x002A INT
0x002B FLOAT
0x002D FLOAT
0x002F FLOAT
0x0031 FLOAT
0x0033 FLOAT
0x0035 FLOAT
0x0037 FLOAT
0x0039 FLOAT
0x003B FLOAT
0x003D FLOAT
0x003F FLOAT
0x0041 FLOAT
0x0043 INT
0x0044 INT
0x0046 INT
0x0047 LONG
0x0049 LONG
0x004B INT
Bit 1
Bit 5
Bit 6
Bit 15

4.2 Set point values

Address Data type/
bit number
0x3100 FLOAT
0x3102 FLOAT
22
Access Signal designation
R/O Limit comparators 1...2
Limit comparator 1 (= 0x0001)
Limit comparator 2 (= 0x0002)
R/W Control of the binary outputs (individual)
Output K1 (= 0x0101)
Output K2 (= 0x0202)
Output K3 (= 0x0404)
Output K4 (= 0x0808)
R/O Analog input [mV]
R/O Internal Pt100 [Ohm]
R/O Sampling cycle time
R/O Analog input [displayed value]
R/O Internal analog value 1
R/O Internal analog value 2
R/O Controller, ramp limit value
R/O Controller, actual value, FILTERED
R/O Controller, actual value, UNFILTERED
R/W Controller set point value
R/O Controller, output value display
R/O Controller, output value, HEATING
R/O Controller, output value, COOLING
R/O Controller, control difference
R/O Controller, control deviation
R/O Controller, switching state, HEATING
R/O Controller, switching state, COOLING
R/O Output value, manual mode
R/O Timer run time
R/O Residual timer time
R/O Timer status
Timer stopped (= 0x0002)
Timer runs (= 0x0020)
Timer end (= 0x0040)
Timer signal (= 0x8000)
Access Signal designation
R/W Set point value W1
R/W Set point value W2
