Moreover, notice that temperature's values of all these four registers are expressed according to
the temperature´s format configured through its onboard DIP-Switches (See "4.3 - DIP-switch
Configuration Interface"). These following formats are possible:
• Celsius value: Value in Modbus register is the temperature value in Celsius (i.e. a
value "22" in the Modbus register must be interpreted as 22ºC).
• Decicelsius value: Value in Modbus register is the temperature value in
decicelsius (i.e. a value "220" in the Modbus register must be interpreted as
22.0ºC).
• Fahrenheit value: Value in Modbus register is the temperature value in
Fahrenheit (i.e. a value "72" in the Modbus register must be interpreted as 72ºF
(~22ºC).
4.2.4 Special behavior – Center/Remote
The Center/Remote register is a feature of the MH-RC-MBS-1 related to the control, and
it can be set to four different options:
- 0: Remote unlock (Center/Remote). The indoor unit is being controlled by a BMS
(Building Management System controlled across to Modbus RTU Master device) and it
can be managed from the BMS, the Remote Controller or the MH-RC-MBS-1.
- 1: Remote lock On/Off (Center). The indoor unit is being controlled by a BMS (Building
Management System controlled across to Modbus RTU Master device) and it can only be
managed by the BMS. In this situation, the MH-RC-MBS-1 is disabled for the On/Off
function.
- 2: Remote lock All (Center). The indoor unit is being controlled by a BMS (Building
Management System controlled from Modbus RTU Master device) and it can only be
managed by the BMS. In this case, the MH-RC-MBS-1 keeps its status as disabled, like
when the device disablement register (7/8) is set to 1.
- 3: Remote (Remote). The indoor unit is not being controlled by any BMS (Building
Management System controlled from Modbus RTU Master device). It can be managed
from the Remote Controller or the MH-RC-MBS-1.
For more information about this setting, please check your Mitsubishi Heavy Industries manual.
For firmware version 0.8 backwards (Check the register 50/51 of other firmware versions). The
values could be as follows:
- 0: Remote unlock (Center/Remote). The indoor unit is being controlled by a BMS
(Building Management System controlled from Modbus RTU Master device) and it can be
managed from the BMS, the Remote Controller or the MH-RC-MBS-1.
- 1: Remote lock (Center). The indoor unit is being controlled by a BMS (Modbus RTU
Master device) and it can only be managed by the BMS (Building Management System
controlled from Modbus RTU Master device). In this case, the MH-RC-MBS-1 keeps its
status as disabled, like when the device disablement register (7/8) is set to 1.
