Info Menu, Continued - ODB SCL800SM-3X Owner's Manual

Figure 5.30.4D
Sort Order (F2) Date/Time (F3) Line/Page (F2)
Figure 5.30.4E
Sort Order (F2) Date/Time (F3) Line/Page (F2)
ODB COMPANY
Service Section
OK
Down
Navigation Buttons
Up
OK
Down

5.30.4 Info Menu, continued

LOGS SCREENS
The Info menu allows the user to view the modules status
as well as the Systems and Events Logs. These screens
are informational only.
LOGS MENU BREAKDOWN
1. System Log - logs for application changes, system
changes or engine related events. (Fig. 5.30.4D) You
can change the sort order (F2), toggle between date
and time (F3) and display Line/Page (F4).
2. Events - logs external switch events such as limit
switch or deadman switches. Not anything with the
engine. (Fig. 5.30.4E). You can change the sort order
(F2), toggle between date and time (F3) and display
Line/Page (F4).
3. Run Time - shows grand total of hours the unit has
run. (Fig. 5.30.4F)
Figure 5.30.4F
800-446-9823
Navigation Buttons
Up
OK
Down
83
SCL800SM3X
