EVERLAST
POWER PLASMA 50
IGBT DESIGN 50AMP PLASMA CUTTER
CC
PAC
IGBT
1
~
PHASE
DC
Operator's Manual For
PowerPlasma 50
Safety, Setup and General Use Guide
Rev. 2
0 00312-13
everlastwelders.com
Specifications and Accessories subject to change without notice.
1-877-755-9353
EVERLAST
329 Littlefield Ave. South San Francisco, CA 94080 USA
