- Page 1 710 Series Turret 510 Series Turret IP Surveillance Camera Quick-Start Guide...
-
Page 2: Box Contents
You must provide: A network connection (and an NVR, if desired) Admin rights to a computer that can access the network Mobile device with Luma Surveillance mobile app (recommended) or CCTV tester Power source: PoE or 12V DC Phillips screwdriver... - Page 3 NVR or through a network router. a powerful remote maintenance tool (see OvrC.com) and lets you use the Luma Surveillance mobile app to check on the camera from anywhere. For installation using this guide, you must be able to access this camera through a personal computer.
-
Page 4: Safety Tips
Luma 510/710 Series Turret Camera Safety Tips Handle this device with care. Do not strike or shake this device. Protect the power cord from being stepped on or pinched, particularly where it connects to the device and the power outlet. Do not operate this device beyond its specified power ratings. - Page 5 Luma 510/710 Series Turret Camera Precautions Before you start, ensure that the device is in good condition and all the assembly parts are included. Also ensure that your recorder has the very latest firmware. Use OvrC to update the firmware, or consult your NVR manual. Ensure that all equipment is powered off during installation.
-
Page 6: Your Camera
Luma 510/710 Series Turret Camera Your Camera Before installing, familiarize yourself with the parts of your camera. Skirt Mounting Screw Trim Ring Indicator Lens and Infrared... - Page 7 Luma 510/710 Series Turret Camera Your Camera’s Utility Port Reset Button CC Test Port SD Card Slot...
- Page 8 Luma 510/710 Series Turret Camera Installation with an NVR If you are installing with an NVR, follow these instructions. Otherwise, follow the instructions starting on the next page. 1. Ensure your NVR has the latest firmware. If it does not, your NVR may be unable to locate and activate your camera.
- Page 9 (prior to physical installation), rather than from atop a ladder. Connect the camera to your PC and run the Luma Utility. It searches for attached Luma Surveillance devices. If your camera does not appear, check the connection, ensure the camera is powered up, then...
-
Page 10: Activate The Camera
Luma 510/710 Series Turret Camera Activate the Camera Click on the entry for your camera to view its details. If the camera is inactive, use the text boxes at the lower right of the Luma utility window to activate the camera by creating a new secure password. - Page 11 Luma 510/710 Series Turret Camera Physical Installation: Wires 1. Drill pilot holes for your screws using the supplied template. 2. Loosen the locking screw and detach the base plate from the camera. Mount the base plate and run the cables through it. 3.
- Page 12 Luma 510/710 Series Turret Camera Physical Installation: Mount and Aim 1. Insert the camera body into the base plate. Twist the camera to lock it in place on the base plate. Tighten the mounting screw. 2. Twist the trim ring to the unlocked position and remove it. 3.
- Page 13 Luma 510/710 Series Turret Camera Start the Web Interface Open your browser and navigate to the camera’s IP address. Below the login area, you may see: “Please click here to download and install the plug-in. Close the browser when installing the plug- in.”...
-
Page 14: Adjust The Camera
Luma 510/710 Series Turret Camera Adjust the Camera The camera itself is mounted in a free-floating ball within the camera body. This free-floating ball can be aimed freely. In addition, if the locking screw is loosened slightly, the entire camera body can rotate. 1. - Page 15 3-Year Limited Warranty This Luma Surveillance™ product has a 3-Year Limited Warranty. This warranty includes parts and labor repairs on all components found to be defective in material or workmanship under normal conditions of use. This warranty shall not apply to products that have been abused, modified or disassembled.
