Luma Surveillance 510 Series Quick Start Manual

Nvr surveillance recorder
Hide thumbs Also See for 510 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
510 Series
NVR Surveillance Recorder
Web Interface
Quick Start
Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 510 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Luma Surveillance 510 Series

Summary of Contents for Luma Surveillance 510 Series

  • Page 1 510 Series NVR Surveillance Recorder Web Interface Quick Start Guide...
  • Page 2 Read this page before you go to the job site! For maximum control and convenience, your system should be connected to the Internet via a local network router. For installation, you must be able to access this network through a personal computer. Internet connectivity allows you to use OvrC, a powerful remote maintenance service.

  • Page 3: Table Of Contents

    Contents Contents Safety Tips ......4 Luma Link ......10 Set Up the Hardware .

  • Page 4: Safety Tips

    510 Series NVR Quick Start Guide Safety Tips Safety Tips Handle this device with care The performance and lifespan of the hard drive is affected by temperature. Use this device in Do not strike or shake this device. temperatures ranging from 14–131 °F.

  • Page 5: Set Up The Hardware

    510 Series NVR Quick Start Guide Set Up the Hardware Set Up the Hardware ß or à Optional local AC Power video monitor LCD Monitor/Flat Panel TV Optional Camera(s) USB Mouse Network Gateway Caution: Do not power up the NVR until these steps are complete.

  • Page 6: Install And Run The Luma Utility

    510 Series NVR Quick Start Guide Install and Run the Luma Utility Install and Run the Luma Utility Use the Luma Utility to locate your surveillance hardware and set up communications. This is a PC-only utility. Visit your product page at SnapAV.com and download the Luma Utility installer from the Support tab.

  • Page 7: Edit The Network Settings

    510 Series NVR Quick Start Guide Edit the Network Settings Edit the Network Settings To change the network settings at a later date, consult the NVR manual. Suggested Best Practices Ensure the Enable DHCP box is activated. In your router, reserve an IP address and assign it to the NVR’s MAC address (found on the recorder’s...

  • Page 8: Optional: Prep For Plugin-Free Browsers

    510 Series NVR Quick Start Guide Optional: Prep for Plugin-Free Browsers Optional: Prep for Plugin-Free Browsers With the update to firmware v3.4.95 build 191127, Chrome, Safari, and Microsoft Edge can view your system remotely. Port forwarding setup allows you to access the NVR from the internet for remote viewing and other operations.

  • Page 9: Complete Port Forwarding

    510 Series NVR Quick Start Guide Complete Port Forwarding Complete Port Forwarding Once you’ve finished, your device’s URL (e.g., MyHome.WirepathDNS.com) gets you to the login page of your NVR, no matter where you are. If you changed your HTTP port from the default location (80), add a colon and the new port number to the URL (e.g., MyHome.WirepathDNS.com:8042).

  • Page 10: Start The Web Interface

    510 Series NVR Quick Start Guide Start the Web Interface Start the Web Interface Get the Luma Plug-In Open your browser, type the IP address of the recorder (from page 7) into the address bar, and hit Return. Below the login window, there may be a link that reads, “Please click here to download and install the plug- in.

  • Page 11: Check The Cameras

    510 Series NVR Quick Start Guide Check the Cameras Check the Cameras After log-in, your screen shows the live page, which should look similar to the illustration below. If a camera is out, check its connection to your NVR, and ensure that it is powered up.

  • Page 12: Set Up Dynamic Dns

    510 Series NVR Quick Start Guide Set Up Dynamic DNS Set Up Dynamic DNS This allows you to connect to your surveillance system from anywhere, via the Internet, using a web address that’s easy to remember. Click on Basic Network Settings > DDNS.

  • Page 13: Camera Passwords

    510 Series NVR Quick Start Guide Camera Passwords Camera Passwords When the Luma NVR is activated, it sets the password for all the connected cameras to match the NVR password that you created on page 6. If you add a camera manually, you must enter the camera’s password.

  • Page 14: Create Users And Set Passwords

    510 Series NVR Quick Start Guide Create Users and Set Passwords Create Users and Set Passwords Click on User Management. Click the Add button. Enter the new account’s user name and password. Account names can be up to 32 characters long, and can contain numbers and letters only.

  • Page 15: Calibrate The System Time

    510 Series NVR Quick Start Guide Calibrate the System Time Calibrate the System Time Click on System Settings and select the Time Settings tab. Synchronize the Time Choose your time zone. North American time zones range from GMT-10:00 (Hawaii) to GMT-03:30 (Newfoundland).

  • Page 16: You're Done

    SnapAV.com. 3-Year Limited Warranty This Luma Surveillance™ product has a 3-Year Limited Warranty. This warranty includes parts and labor repairs on all components found to be defective in material or workmanship under normal conditions of use. This warranty shall not apply to products that have been abused, modified or disassembled.
