The zone leak detection kit provides leak detection for a defined zone. This kit is ideal for perimeter
sensing or serpentine coverage of small areas. A simple, two-wire connection signals the alarms at a
Liebert Thermal Management unit or at a monitoring panel. Run wires to the Liebert unit and
connect them to terminals 24 and 51, 55 or 56. The sensor utilizes Liebert's LT500Y leak detection
cable. The kit is offered with five different lengths of cable sized specifically for the type of Liebert
Thermal Management unit (see matrix below). Refer to matrix below for the recommended location of
leak detection cable.
Table 1 Zone leak detection kit installation scenarios
In back
On sides
In front
Unit (footprint-in.)
Liebert Challenger 3000
(32.5 x 32.5)
Remote Shutdown
A connection point is provided for customer supplied remote shutdown devices. This terminal strip is
located at the top of upflow units, and at the base of downflow units. Terminals 37 and 38 on the
terminal strip are jumpered when no remote shutdown device is installed.
3.2

Filters

Filters are usually the most neglected item in an environmental control system. To maintain efficient
operation, they should be checked monthly and changed as required. Because replacement intervals
vary with environmental condition and filter type, each unit is equipped with a filter clog switch. This
warns of restricted airflow through the filter compartment by activating the Change Filter alarm.
Turn power Off before replacing filters.
Liebert Challenger 3000 filters are 28-1/2" by 29-1/2", either 2" or 4" thick, plus an optional 2" thick
pre-filter. The filter is replaced from the front of the unit. On upflow units, the filter is vertical, in
front of the lower compartment. Pull the filter out toward you to remove it. On downflow units, the
filter is horizontal, above the electrical panel. Slide the filter out toward you to remove it.
After replacing the filter(s), test the operation of the filter clog switch. Turn the adjusting screw
counter clockwise to trip the switch — this will energize the Change Filter alarm. To adjust the
switch proceed as follows: With the fan running, set the switch to energize the light with clean filters.
The unit panels must all be in place and closed to accurately find this point. Then turn the adjusting
knob one turn clockwise, or to the desired filter change point.
Upflow Unit Upflow Unit
Detection Detection on sides
around and
entire unit in front of unit
2-ft clearance 2-ft clearance
in front in front
Distance From Unit, feet (m)
2 (0.6) No cable behind
2 (0.6) 2 (0.6)
2 (0.6) 2 (0.6)
LT460-Z30 LT460-Z20
9
Component Operation and Maintenance
Scenarios
Downflow Unit
Detection Detection on sides
around
entire unit
6-ft clearance
in front
1 (0.3)
1 (0.3)
6 (1.8)
Part Number
LT460-Z30
Liebert
Downflow Unit
and
in front of unit
6-ft clearance
in front
No cable behind
1 (0.3)
6 (1.8)
LT460-Z25
™
® Challenger 3000
