  • Page 1 » User Guide « CP-RIO6-001 CP-RIO6-001-DD-216 CP-RIO6-001-HD CP-RIO6-001-HD-216 6U CompactPCI Rear Transition Modules Doc. ID: 1043-5620, Rev. 2.0 August 17, 2012 If it’s embedded, it’s Kontron.

  • Page 2: Imprint

    Disclaimer Copyright © 2012 Kontron AG. All rights reserved. All data is for information purposes only and not guaranteed for legal purposes. Information has been carefully checked and is believed to be accurate; however, no responsibility is assumed for inaccuracies. Kontron and the Kontron logo and all other trademarks or registered trademarks are the property of their respective own- ers and are recognized.

  • Page 3: Table Of Contents

    Two Year Warranty ....................xiii Introduction ................1 - 3 1.1 Board Overview ..................1 - 3 1.2 CP-RIO6-001/-DD-216/-HD/-HD-216 Feature Comparison ....1 - 4 1.3 Board Diagrams ..................1 - 4 1.3.1 Functional Block Diagrams ............. 1 - 5 1.3.2...
  • Page 4 Preface CP-RIO6-001/-DD-216/-HD/-HD-216 2.1.3 Gigabit Ethernet Interfaces .............2 - 6 2.1.4 Serial ATA Interfaces ...............2 - 7 2.1.4.1 SATA Connector J17 ..............2 - 7 2.1.4.2 SATA Connector J19 (optional) ..........2 - 8 2.1.5 COM Interfaces ................2 - 9 2.1.6 FAN Connectors ................2 - 10 2.1.7...

  • Page 5: List Of Tables

    Fan Control Con. J12 and J13 Pinout ............. 2 - 10 CP-RIO6-001/-HD Rear I/O CompactPCI Connector rJ3 Pinout ..... 2 - 12 2-10 CP-RIO6-001/-HD Rear I/O CompactPCI Connector rJ3 Signals ... 2 - 12 2-11 CP-RIO6-001- /DD-216/HD-216 Rear I/O CompactPCI Connector rJ3 Pinout ......................
  • Page 6 Preface CP-RIO6-001/-DD-216/-HD/-HD-216 This page has been intentionally left blank. Page vi ID 1043-5620, Rev. 2.0...

  • Page 7: List Of Figures

    CP-RIO6-001-HD/CP-RIO6-001-HD-216 Functional Block Diagram ..1 - 6 CP-RIO6-001/-DD-216/-HD/-HD-216 Front Panels ......... 1 - 7 CP-RIO6-001/CP-RIO6-001-DD-216 Board Layout – Front View ... 1 - 8 CP-RIO6-001-HD/CP-RIO6-001-HD-216 Board Layout – Front View ..1 - 9 USB Con. J6 and J7 ................2 - 3 USB NAND Flash Con.
  • Page 8 Preface CP-RIO6-001/-DD-216/-HD/-HD-216 This page has been intentionally left blank. Page viii ID 1043-5620, Rev. 2.0...

  • Page 9: Proprietary Note

    Kontron without further notice. Trademarks Kontron, the PEP logo and, if occurring in this manual, “CXM” are trademarks owned by Kon- tron, Kaufbeuren (Germany). In addition, this document may include names, company logos and trademarks, which are registered trademarks and, therefore, proprietary to their respective owners.

  • Page 10: Explanation Of Symbols

    Preface CP-RIO6-001/-DD-216/-HD/-HD-216 Explanation of Symbols Caution, Electric Shock! This symbol and title warn of hazards due to electrical shocks (> 60V) when touching products or parts of them. Failure to observe the pre- cautions indicated and/or prescribed by the law may endanger your life/health and/or result in damage to your material.

  • Page 11: For Your Safety

    However, the life expectancy of your product can be drastically reduced by improper treatment during unpacking and installation. Therefore, in the interest of your own safety and of the correct operation of your new Kontron product, you are requested to conform with the following guidelines.

  • Page 12: General Instructions On Usage

    CP-RIO6-001/-DD-216/-HD/-HD-216 General Instructions on Usage In order to maintain Kontron’s product warranty, this product must not be altered or modified in any way. Changes or modifications to the device, which are not explicitly approved by Kontron and described in this manual or received from Kontron’s Technical Support as a special handling instruction, will void your warranty.

  • Page 13: Two Year Warranty

    As a result, the products are sold “as is,” and the responsibility to ensure their suitability for any given task remains that of the purchaser. In no event will Kontron be liable for direct, indirect or consequential damages resulting from the use of our hardware or software products, or documentation, even if Kontron were advised of the possibility of such claims prior to the purchase of the product or during any period since the date of its purchase.
  • Page 14 Preface CP-RIO6-001/-DD-216/-HD/-HD-216 This page has been intentionally left blank. Page xiv ID 1043-5620, Rev. 2.0...

  • Page 15: Introduction

    CP-RIO6-001/-DD-216/-HD/-HD-216 Introduction Chapter Introduction ID 1043-5620, Rev. 2.0 Page 1 - 1...
  • Page 16 Introduction CP-RIO6-001/-DD-216/-HD/-HD-216 This page has been intentionally left blank. Page 1 - 2 ID 1043-5620, Rev. 2.0...

  • Page 17: Board Overview

    RIO6-001-HD and the CP-RIO6-001-HD-216 provide support for one onboard 2.5" SATA HDD/ SSD. The CP-RIO6-001 comes with three USB 2.0 ports, two Gigabit Ethernet ports with LED sig- nals, two digital video ports, one onboard SATA port, two onboard COM ports and two onboard fan connectors.

  • Page 18: Cp-Rio6-001/-Dd-216/-Hd/-Hd-216 Feature Comparison

    Introduction CP-RIO6-001/-DD-216/-HD/-HD-216 CP-RIO6-001/-DD-216/-HD/-HD-216 Feature Comparison The following table provides a feature comparison of the CP-RIO6-001/-DD-216/-HD/-HD-216 modules. Table 1-1: CP-RIO6-001/-DD-216/-HD/-HD-216 Feature Comparison CP-RIO6-001- CP-RIO6-001- CP-RIO6-001- PORT CP-RIO6-001 DD-216 HD-216 Digital video port Gigabit Ethernet -- * -- * USB 2.0 USB 2.0 NAND...

  • Page 19: Functional Block Diagrams

    CP-RIO6-001/-DD-216/-HD/-HD-216 Introduction 1.3.1 Functional Block Diagrams Figure 1-1: CP-RIO6-001/CP-RIO6-001-DD-216 Functional Block Diagram HDMI/DVI Connector Connector CPCI Connectors COM1 RS-232 (10-pin) SATA Connector (7-pin) USB NAND Flash 2x USB2.0 2x USB Not available on the CP-RIO6-001-DD-216 2x GbE 2x Mag FAN1...

  • Page 20: Cp-Rio6-001-Hd/Cp-Rio6-001-Hd-216 Functional Block Diagram

    Introduction CP-RIO6-001/-DD-216/-HD/-HD-216 Figure 1-2: CP-RIO6-001-HD/CP-RIO6-001-HD-216 Functional Block Diagram HDMI/DVI Connector COM1 RS-232 (10-pin) SATA Connector CPCI (7-pin) Connectors SATA Socket USB NAND Flash 2x USB2.0 2x USB Not available on the CP-RIO6-001-HD-216 2x GbE 2x Mag FAN1 Sense FAN2 COM2...

  • Page 21: Front Panels

    CP-RIO6-001/-DD-216/-HD/-HD-216 Introduction 1.3.2 Front Panels Figure 1-3: CP-RIO6-001/-DD-216/-HD/-HD-216 Front Panels CP-RIO6-001 CP-RIO6-001-DD-216 CP-RIO6-001-HD CP-RIO6-001-HD-216 ID 1043-5620, Rev. 2.0 Page 1 - 7...

  • Page 22: Board Layout

    Introduction CP-RIO6-001/-DD-216/-HD/-HD-216 1.3.3 Board Layout Figure 1-4: CP-RIO6-001/CP-RIO6-001-DD-216 Board Layout – Front View HDMI/DVI HDMI/DVI 10 9 (COM A) 10 9 Magn. (COM B) (SATA) Protective Caps Magn. CP-RIO6-001-DD-216 only NAND Flash Page 1 - 8 ID 1043-5620, Rev. 2.0...

  • Page 23: Cp-Rio6-001-Hd/Cp-Rio6-001-Hd-216 Board Layout - Front View

    CP-RIO6-001/-DD-216/-HD/-HD-216 Introduction Figure 1-5: CP-RIO6-001-HD/CP-RIO6-001-HD-216 Board Layout – Front View (SATA) DVI/HDMI 10 9 (COM A) 10 9 Magn. (COM B) (SATA) Protective Caps Magn. CP-RIO6-001-HD-216 only NAND Flash ID 1043-5620, Rev. 2.0 Page 1 - 9...

  • Page 24: Technical Specification

    Introduction CP-RIO6-001/-DD-216/-HD/-HD-216 Technical Specification Table 1-2: CP-RIO6-001/-DD-216/-HD/-HD-216 Main Specifications CP-RIO6-001/-DD-216/ SPECIFICATIONS -HD/-HD-216 Digital Video CP-RIO6-001, CP-RIO6-001-DD-216: • Two digital video interfaces implemented as two 29-pin DVI-I con- nectors, J9 and J11, supporting HDMI and DVI signaling for digital monitors (no analog video signals on these connectors) CP-RIO6-001-HD, CP-RIO6-001-HD-216: •...
  • Page 25 CP-RIO6-001/-DD-216/-HD/-HD-216 Introduction Table 1-2: CP-RIO6-001/-DD-216/-HD/-HD-216 Main Specifications (Continued) CP-RIO6-001/-DD-216/ SPECIFICATIONS -HD/-HD-216 Temperature Range Operational: 0°C to +60°C Standard -40°C to +85°C E2 (optional) Storage: -55°C to +85°C Without any additional components Note ... When additional components are installed, refer to their operational specifications as this will influ- ence the modules’...

  • Page 26: Standards

    Customers desiring to perform further environmental testing of Kontron prod- ucts must contact Kontron for assistance prior to performing any such testing. This is necessary, as it is possible that environmental testing can be destructive when not performed in accordance with the applicable specifications.

  • Page 27: Related Publications

    CP-RIO6-001/-DD-216/-HD/-HD-216 Introduction Related Publications The following publications contain information relating to the CP-RIO6-001/-DD-216/-HD/-HD- 216. Table 1-4: Related Publications PRODUCT PUBLICATION CompactPCI Systems and CompactPCI Specification 2.0, Rev. 3.0 Boards CompactPCI Packet Switching Backplane Specification PICMG 2.16 Rev. 1.0 (CP-RIO6-001-DD-216/CP-RIO6-001-HD-216) Kontron CompactPCI Backplane Manual, ID 24229...
  • Page 28 Introduction CP-RIO6-001/-DD-216/-HD/-HD-216 This page has been intentionally left blank. Page 1 - 14 ID 1043-5620, Rev. 2.0...

  • Page 29: Functional Description

    CP-RIO6-001/-DD-216/-HD/-HD-216 Functional Description Chapter Functional Description ID 1043-5620, Rev. 2.0 Page 2 - 1...
  • Page 30 Functional Description CP-RIO6-001/-DD-216/-HD/-HD-216 This page has been intentionally left blank. Page 2 - 2 ID 1043-5620, Rev. 2.0...

  • Page 31: Board Interfaces

    2.0 it is strongly recommended to use a cable length not exceeding 3 meters. 2.1.1.1 Front Panel USB Connectors J6 and J7 On the front panel of the CP-RIO6-001/-DD-216/-HD/-HD-216 rear I/O module, there are two USB interfaces implemented on two 4-pin connectors with the following pinout: Figure 2-1: USB Con.

  • Page 32: Onboard Usb Nand Flash Connector J18

    The J18 connector is used to connect an optional USB 2.0 NAND Flash module qualified by Kontron. The USB 2.0 NAND Flash module is a USB 2.0-based NAND Flash drive with a built- in full hard-disk emulation and a high data transfer rate. It is optimized for embedded systems providing high performance, reliability and security.

  • Page 33: Digital Video Interfaces

    HDMI and DVI signaling depending on the CPU board and the monitor capability. The CP-RIO6-001 and CP-RIO6-001-DD-216 rear I/O modules provide two digital video inter- faces implemented as two 29-pin DVI connectors, J9 and J11, which allow for simultaneous connection of two digital monitors.

  • Page 34: Gigabit Ethernet Interfaces

    CP-RIO6-001/-DD-216/-HD/-HD-216 2.1.3 Gigabit Ethernet Interfaces The CP-RIO6-001 and the CP-RIO6-001-HD provide a Gigabit Ethernet interface implemented as one dual, RJ-45 Ethernet connector J8A/B. The CP-RIO6-001-DD-216 and CP-RIO6-001-HD-216 are populated with an Ethernet connector, J8A/B, but the Ethernet interface is isolated on the CompactPCI connector rJ3. Flat dummy plugs are fitted to these connectors as protective caps to prevent their unintentional use.

  • Page 35: Serial Ata Interfaces

    The CP-RIO6-001 and CP-RIO6-001-DD-216 provide one Serial ATA (SATA) interface for con- necting a SATA device to the module via a SATA cable. The CP-RIO6-001-HD and the CP- RIO6-001-HD-216 provide two SATA interfaces, one for connecting a standard 2.5" SATA HDD/SSD and one for connecting a SATA device via a SATA cable.

  • Page 36: Sata Connector J19 (Optional)

    2.1.4.2 SATA Connector J19 (optional) The CP-RIO6-001-HD and the CP-RIO6-001-HD-216 rear I/O modules are equipped with the SATA connector J19 used to connect a 2.5” SATA HDD/SSD to the rear I/O module. The con- nector is divided into two segments, a signal segment and a power segment.

  • Page 37: Com Interfaces

    Functional Description 2.1.5 COM Interfaces The CP-RIO6-001/-DD-216/-HD/-HD-216 rear I/O module provides two COM ports for con- necting RS-232 (COMA) and RS-232/RS-422 (COMB) devices, depending on the CPU board. The following figures and tables provide pinout information for the onboard COM connectors J15 (COM B) and J16 (COM A).

  • Page 38: Fan Connectors

    Functional Description CP-RIO6-001/-DD-216/-HD/-HD-216 2.1.6 FAN Connectors The CP-RIO6-001/-DD-216/-HD/-HD-216 module has two 3-pin, onboard fan connectors, J12 and J13, for connecting two external cooling fans. Figure 2-8: Fan Control Con. J12 Table 2-8: Fan Control Con. J12 and J13 Pinout and J13...

  • Page 39: Rear I/O Interface On Compact Pci Connectors Rj3, Rj4 And Rj5

    Functional Description 2.1.7 Rear I/O interface on Compact PCI Connectors rJ3, rJ4 and rJ5 The CP-RIO6-001/-DD-216/-HD/-HD-216 rear I/O module is equipped with three CompactPCI rear I/O connectors, rJ3, rJ4 and rJ5. Note ... To support the rear I/O feature, a 6U CompactPCI backplane with rear I/O sup- port as well as a compatible and correctly configured CPU board are required.

  • Page 40: Cp-Rio6-001/-Hd Rear I/O Compactpci Connector Rj3 Pinout

    I/O module. Failure to comply with the above will result in damage to your board. The following table describes the signals of the rJ3 connector used on the CP-RIO6-001/-HD. Table 2-10: CP-RIO6-001/-HD Rear I/O CompactPCI Connector rJ3 Signals...

  • Page 41: Cp-Rio6-001- /Dd-216/Hd-216 Rear I/O Compactpci Connector Rj3

    I/O module. Failure to comply with the above will result in damage to your board. The following table describes the signals of the rJ3 connector used on the CP-RIO6-001- /DD- 216/HD-216:...

  • Page 42: Rear I/O Compactpci Connector Rj4 Pinout

    Functional Description CP-RIO6-001/-DD-216/-HD/-HD-216 Table 2-13: Rear I/O CompactPCI Connector rJ4 Pinout RIO_VCC RIO_3.3V 12-14 Key Area Warning! The RIO_XXX signals are power supply INPUTS to supply the rear I/O module with power from the CPU board. These pins MUST NOT be connected to any other power source, either within the backplane itself or within a rear I/O mod- ule.

  • Page 43: Rear I/O Compactpci Rear I/O Connector Rj5 Signals

    CP-RIO6-001/-DD-216/-HD/-HD-216 Functional Description Table 2-14: Rear I/O CompactPCI Connector rJ5 Pinout PWM1:OUT PWM2:OUT DVI2:D0+ DVI2:D0- DVI2:D2+ DVI2:D2- DVI2:D1+ DVI2:D1- DVI2:HPDET DVI2:CLK+ DVI2:CLK- DVI2:SDA DVI2:SDC DVI1:D0+ DVI1:D0- DVI1:D1+ DVI1:D1- DVI1:D2+ DVI1:D2- DVI1:HPDET DVI1:SDA DVI1:SDC DVI1:CLK+ DVI1:CLK- HT3:TX+ HT3:TX- HT3:RX+ HT3:RX- HT1:TX+...
  • Page 44 Functional Description CP-RIO6-001/-DD-216/-HD/-HD-216 This page has been intentionally left blank. Page 2 - 16 ID 1043-5620, Rev. 2.0...

  • Page 45: Installation

    CP-RIO6-001/-DD-216/-HD/-HD-216 Installation Chapter Installation ID 1043-5620, Rev. 2.0 Page 3 - 1...
  • Page 46 Installation CP-RIO6-001/-DD-216/-HD/-HD-216 This page has been intentionally left blank. Page 3 - 2 ID 1043-5620, Rev. 2.0...

  • Page 47: Safety Requirements

    The CP-RIO6-001/-DD-216/-HD/-HD-216 has been designed for easy installation. However, the following standard precautions, installation procedures, and general information must be observed to ensure proper installation and to preclude damage to the CP-RIO6-001/-DD-216/ -HD/-HD-216, other system components, or injury to personnel.

  • Page 48: Rear I/O Module Installation Procedures

    (con- necting or disconnecting). Kontron disclaims all liability for damages or injuries resulting from failure to comply with the above. Warning! When performing the next step, DO NOT push the rear I/O module into the backplane connectors.

  • Page 49: Rear I/O Module Removal Procedures

    (con- necting or disconnecting). Kontron disclaims all liability for damages or injuries resulting from failure to comply with the above. 3. Disconnect and secure any interfacing cables that may be connected to the rear I/O module.

  • Page 50: Usb 2.0 Nand Flash Module Installation

    One USB 2.0 NAND Flash module may be connected to the CP-RIO6-001/-DD-216/-HD/-HD- 216 via the onboard USB 2.0 NAND Flash connector, J18. The USB 2.0 NAND Flash module must be physically installed on the CP-RIO6-001/-DD-216/ -HD/-HD-216 prior to installation of the rear I/O module in a system.

  • Page 51: Installation Of A 2.5" Sata Hdd/Ssd Device

    SATA connector and properly secured via the four mounting screws. The following figure shows the placement of the 2.5” SATA HDD/SSD on the CP-RIO6-001- /HD/HD-216. Figure 3-1: Placement of the 2.5” SATA HDD/SSD on the CP-RIO6-001- /HD/HD-216 2.5”...
  • Page 52 Installation CP-RIO6-001/-DD-216/-HD/-HD-216 This page has been intentionally left blank. Page 3 - 8 ID 1043-5620, Rev. 2.0...
