Contact:
HONGKONG XUHUA INDUSTRIAL CO., LTD.
RM 605, 6/F DAVID HSE 8-20 NANKING ST JORDAN KL, HONGKONG
E-mail: service.usuk@lifehoodglobal.com
Guangdong Transtek Medical Electronics Co., Ltd.
Zone B, No.105 ,Dongli Road, Torch Development District,
Zhongshan,528437,Guangdong,China
User Manual
Blood Pressure Monitor
If any quality questions or confusion, feel free to contact us via
E-mail: service.usuk@lifehoodglobal.com.
Please do read the user manual carefully and thoroughtly so as to ensure the
safe usage of this product, and keep the manual well for further reference in
case you have problems.
version:1.0
Arm Type
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TRANSTEK LIFEHOOD TMB-1775
Summary of Contents for TRANSTEK LIFEHOOD TMB-1775
- Page 1 If any quality questions or confusion, feel free to contact us via E-mail: service.usuk@lifehoodglobal.com. Guangdong Transtek Medical Electronics Co., Ltd. Please do read the user manual carefully and thoroughtly so as to ensure the Zone B, No.105 ,Dongli Road, Torch Development District,...
-
Page 2: Table Of Contents
CATALOGUE Table of Contents INTRODUCTION ...............3 General Description Indications for Use Contraindications Measurement Principle LCD Display Signal Monitor Components List BEFORE YOU START ............8 The Choice of Power Supply Installing and Replacing the Batteries Setting Date, Time MEASUREMENT................13 Tie the Cuff Start the Measurement DATA MANAGEMENT..............17 Recall the Records... -
Page 3: Introduction
CATALOGUE INTRODUCTION General Description ABOUT BLOOD PRESSURE............21 Thank you for selecting LIFEHOOD arm type blood pressure What are systolic pressure and diastolic pressure? monitor (TMB-1775). The monitor features blood pressure What is the standard blood pressure classification? measurement, pulse rate measurement and the result storage. Irregular heartbeat detector The design provides you with two years of reliable service. -
Page 4: Measurement Principle
INTRODUCTION INTRODUCTION Measurement Principle This product uses the Oscillometric Measuring method to detect SYMBOL DESCRIPTION EXPLANATION blood pressure. Before every measurement, the unit establishes a “zero pressure” equivalent to the air pressure.Then it starts High blood pressure Systolic pressure inflating the arm cuff, meanwhile, the unit detects pressure oscillations generated by beat-to-beat pulsatile, which is used to Diastolic pressure Low blood pressure... -
Page 5: Lcd Display Signal
INTRODUCTION INTRODUCTION Monitor Components List 1.Blood Pressure Monitor (TMB-1775) CUFF AIR TUBE AIR CONNECTOR PLUG 2.Cuff (Type BF applied part) : 8.75"- 16.5"(22cm~42cm) MEMORY BUTTON START/STOP LCD DISPLAY (Please use LIFEHOOD authorized BUTTON cuff. The size of the actual cuff please refer to the label on the BATTERY attached cuff.) -
Page 6: Before You Start
BEFORE YOU START BEFORE YOU START The Choice of Power Supply Replace the batteries whenever the below happens Battery powered mode: shows 6VDC 4×AAA batteries The display is dim CAUTION The display does not light up. In order to get the optimal performance and protect your monitor, please use the correct batteries. -
Page 7: Setting Date, Time
BEFORE YOU START BEFORE YOU START Setting Date and Time. mmHg It is important to set the date and time before using your blood Press “ START/STOP ” button pressure monitor, so that a time stamp can be assigned to to confirm [YEAR]. -
Page 8: Measurement
BEFORE YOU START MEASUREMENT Applying the Arm Cuff Repeat step 2 and 3 to set the [HOUR] and [MINUTE]. To achieve an accurate blood pressure reading, follow these steps to position the blood pressure cuff properly. mmHg mmHg 1. Remove tight-fitting clothing or tight rolled up sleeve from your left upper arm. -
Page 9: Start The Measurement
MEASUREMENT MEASUREMENT Start the Measurement How to Sit Correctly Press the “START/STOP” button to power up the monitor and To take a measurement, you need to be relaxed and comfortably begin the blood pressure measurement. seated,under comfortable room temperature. Avoid bathing, LCD display START drinking alcohol or caffeine, smoking, exercising or eating 30... -
Page 10: Data Management
MEASUREMENT DATA MANAGEMENT Recall the Records Press the “START/STOP” button to turn the monitor off. It will automatically turn off within 1 minute. 1. When the monitor is off, please press “ M ” mmHg button to show the average value of the latest three records.If the records are less than 3 groups, it will display the latest mmHg... -
Page 11: Delete The Records
DATA MANAGEMENT INFORMATION FOR USER Delete the Records Tips for Measurement If you did not get the correct measurement, you can delete Measurements may be inaccurate if taken in the following all results for the selected user by following steps below . circumstances. -
Page 12: About Blood Pressure
INFORMATION FOR USER ABOUT BLOOD PRESSURE Maintenance What are systolic pressure and diastolic pressure? Systolic When ventricles contract and pump blood out of In order to get the best performance, please follow the blood discharging artery the heart, the blood pressure reaches its maximum instructions below . -
Page 13: Irregular Heartbeat Detector
ABOUT BLOOD PRESSURE ABOUT BLOOD PRESSURE CAUTION CAUTION The appearance of the IHB icon indicates that a pulse irregularity Only a physician can tell your normal BP range. Please contact a consistent with an irregular heart-beat was detected during physician if your measuring result falls out of the range. Please measurement. -
Page 14: Troubleshooting
ABOUT BLOOD PRESSURE TROUBLE SHOOTING This section includes a list of error messages and frequently asked What you need to pay attention to when you measure your questions for problems you may encounter with your blood pressure blood pressure at home: monitor. -
Page 15: Specifications
SPECIFICATIONS SPECIFICATIONS External dimensions Battery powered mode: Approx.120.2mm×108.2mm×68.5mm Power supply 6VDC 4×AAA batteries Attachment 4×AAA batteries,user manual Continuous operation Display mode V.A.65×50mm Mode of operation Degree of protection Type BF applied part Oscillographic testing mode Measurement mode IP21 It means the device could protected against solid foreign objects of 12.5mm Protection against Rated cuff pressure:... -
Page 16: Safety Information
SAFETY INFORMATION SAFETY INFORMATION Safety Information CAUTION The signs below might be in the user manual,labeling or other component. * Be careful to strangulation due to cables and hoses, particularly They are the requirement of standard and using. due to excessive length. * At least 30 min required for ME equipment to warm from the minimum storage temperature between uses until it is ready for intended use. - Page 17 SAFETY INFORMATION SAFETY INFORMATION CAUTION CAUTION * On the rare occasion of a fault causing the cuff to remain fully * The device is not intended for patient transport outside a healthcare facility. inflated during measurement, open the cuff immediately. Prolonged high pressure (cuff pressure >...
- Page 18 SERVICE PERSONNEL of the cuff have been tested and found to comply with requirements of Transtek. Don’t open or repair the device by yourself in the event of ISO 10993-5:2009 and ISO 10993-10:2010. It will not cause any of malfunctions.
-
Page 19: Contact Information
Lifehood will serve you anytime. EN ISO 15223-1:2016/ ISO 15223-1:2016 Medical devices. Manufactured by: Symbols to be used with medical device labels, labelling Guangdong Transtek Medical Electronics Co., Ltd. Labeling and information to be supplied. Part 1 : General requirements Company: Guangdong Transtek Medical Electronics Co., Ltd. -
Page 20: Emc Guidance
COMPLIED STANDARDS LIST EMC GUIDANCE Complied Standards List EMC Guidance 1)This product needs special precautions regarding EMC and needs EN 1060-4:2004 Non-invasive sphygmomanometers to be installed and put into service according to the EMC information -Part 4: Test procedures to determine the overall provided, and this unit can be affected by portable and mobile RF Clinical system accuracy of automated non-invasive... - Page 21 EMC GUIDANCE EMC GUIDANCE Table 3 Table 2 Guidance and manufacturer’s declaration Guidance and manufacturer’s declaration – electromagnetic immunity – electromagnetic immunity The device is intended for use in the electromagnetic environment The device is intended for use in the electromagnetic environment specified below.
- Page 22 EMC GUIDANCE EMC GUIDANCE Table 4 Table 3 Recommended separation distances between portable and NOTE 1 At 80 MHz and 800 MHz, the higher frequency range applies. mobile RF communications equipment and the device. NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects and people.
- Page 23 EMC GUIDANCE EMC GUIDANCE Guidance and manufacturer’s declaration - electromagnetic immunity The device is intended for use in the electromagnetic environment specified below. The customer or the user of the device should assure that it is used in such an environment. Radiated RF Test IMMUNITY...
- Page 24 EMC GUIDANCE Table 5 NOTE If necessary to achieve the IMMUNITY TEST LEVEL, the distance between the transmitting antenna and the ME EQUIPMENT or ME SYSTEM may be reduced to 1 m. The 1 m test distance is permitted by IEC 61000-4-3. a) For some services, only the uplink frequencies are included.
