- Page 1 User Manual WINIX AIR PURIFIER ZERO (AZBU330-HWE) Model ˍ Please read and follow all safety rules and instructions Use & Care in this manual before operating. Guide ˍ The product warranty is printed on the back of this guide, so please keep it in a safe place for future use.
-
Page 2: Table Of Contents
CONTENTS 4-STAGE AIR PURIFICATION · · ············································ 3 CONTROLS ····························································· 4 WHERE TO USE ························································· 5 INSTALLING FILTERS ···················································· 6 SAFETY AND CAUTIONS · · ··············································· 8 INITIAL OPERATION ····················································· 9 AUTO & SLEEP ························································· 10 MANUAL & TIMER · · ···················································· 11 PLASMAWAVE ®... -
Page 3: 4-Stage Air Purification
➊ Pre-filter Power cord with plug (This product is suitable for 220V ~ 240V only.) Front panel User Manual WINIX AIR PURIFIER Model AZBU330-HWE •Please read and follow all safety rules and Use & Care instructions in this manual before operating. -
Page 4: Controls
CONTROLS Outlet Vent 소피아 1 Reset Button PlasmaWave Indicator After replacing a lter, Indicates whether press the RESET button PlasmaWave is enabled or for at least 5 seconds. disabled. Timer Indicator If timer has been set, the LED light indicates the set time of operation. -
Page 5: Where To Use
WHERE TO USE Allow 30 - 45 cm. of space between TVs, radios, and other electronic products electromagnetic interference from certain electronics may cause product malfunction. Place indoors away from direct sun light direct exposure may cause product malfunction or failure. Only place on hard, flat surfaces flimsy or slanted surfaces may result in abnormal noise and vibrations. -
Page 6: Installing Filters
INSTALLING FILTERS This product comes with all required filters. The protective plastic wrap must be removed from the filter before use. ※ Operating the unit without removing the plastic wrap may result in product failure. ※ Unplug and make sure the unit is turned off before installing filter. Remove the front panel by grasping its ①... - Page 7 ※ Intervals between filter replacement may vary depending on environment. ※ For optimal use, Pre-filter can be cleaned once every 14 days which can extend the life of other filters. To purchase replacement Winix filters: FILTER this unit contact your local dealer...
-
Page 8: Safety And Cautions
SAFETY AND CAUTIONS Before operating this equipment, carefully read and follow these safety cautions Ensure filters are inserted before running unit running unit without filters can shorten the units life and cause electric shock or injury. Be sure foreign objects are NOT inserted into the vents on the unit objects can include pins, rods, and coins. -
Page 9: Initial Operation
INITIAL OPERATION Insert the power cord into an electrical ① outlet. Press the ‘Power’ button. ② 소피아 1 ˍ During the first 30 seconds of power up, the Air Quality Note Indicator will cycle through Blue, Yellow and Red colors. The Particle Sensors take approximately 30 seconds to gauge the air quality in the environment, after which normal operation will begin. -
Page 10: Auto & Sleep
AUTO & SLEEP 1. Auto Mode Enables auto operation based on the unit's air quality Particle Sensor. Press the Mode button to select Auto mode. ① ˍ The LED ‘Auto’ light will indicate when Auto mode is activated, and operation will begin. -
Page 11: Manual & Timer
MANUAL & TIMER 3. Manual Mode (setting fan speed) Users can opt to manually set the fan speed to Low, Medium, High, or Turbo. Press the Fan Speed button to set the ① desired fan speed. ˍ When Manual Mode is selected, Auto Mode is automatically Note disabled. -
Page 12: Plasmawave
PLASMAWAVE ® & AIR QUALITY INDICATOR 5. PlasmaWave ® ® By default, PlasmaWave is enabled whenever the unit is powered on. Press the Plasmawave button, when the unit ① is on, to enable or disable this feature. ˍ In Auto mode, as the indoor air quality improves, the fan Note speed will automatically be reduced to Low. -
Page 13: Filter Care
※ Intervals between filter replacement may vary depending on environment. ※ For optimal use, Pre-filter can be cleaned once every 14 days which can extend the life of other filters. To purchase replacement FILTER Winix filters: this unit is compatible contact your local dealer with this filter... - Page 14 ˍ Operating the unit without removing filters from plastic wrap may cause abnormal noise, deformation, or fire as a result of overheating. ˍ For optimal performance, only Winix filters should be used NOTICE with this unit. English ZERO...
- Page 15 FILTER CARE 4. Replacing Filters Insert the True HEPA Filter first, then the ① Carbon filter. True HEPA filter Carbon filter Insert the Pre-filter. ② Tabs ˍ Insert bottom tabs of the Pre-filter into the slots on either side of the lower part of the unit, then rotate upward to insert the upper tabs into the slots at the top part of the unit until sides audibly click...
- Page 16 FILTER CARE 6. Cleaning the filter Intervals between filter cleaning may vary depending on the air quality. Use a vacuum cleaner or soft brush to ① clean the Pre-filter. If it is excessively soiled, rinse in room temperature water. ˍ Do not use detergent or soap. ˍ...
-
Page 17: Particle Sensor Care
PARTICLE SENSOR CARE Particle Sensors Care For optimal performance of the Particle Sensor, which detects airborne dust and ultrafine particles, clean it every two months. Clean it more frequently when the unit is running in a place with high dust levels. Open the Particle Sensor cover. -
Page 18: Cleaning Care
CLEANING CARE 1. Cleaning the Exterior & Interior Wipe with a soft damp cloth using room ① temperature water. Afterwards, wipe it down with a clean dry cloth. ˍ To keep unit in peak condition, clean every 1-2 months. Open the front panel and clean the interior ②... -
Page 19: Frequently Asked Questions
FREQUENTLY ASKED QUESTIONS Problem Check / Actions to take ˍ Is the plug securely attached to the outlet? - Make sure the outlet has power going to it, and ensure the plug is secured. It does not turn on at all. ˍ... - Page 20 FREQUENTLY ASKED QUESTIONS Problem Check / Actions to take ˍ Is the plug securely plugged in? The power plug and outlet feel - Make sure the plug is properly plugged into the hot. outlet. ˍ Is it being used in a place with a lot of smoke, dust, or odours? There is a strange - Clean the air intakes on either side and clean...
-
Page 21: Unit Specifications
UNIT SPECIFICATIONS Model Name ZERO (AZBU330-HWK) Power Voltage AC 220 V - 240 V ~ 50 / 60 Hz Power Rate 70 W Max Room Capacity 99 m Dimensions 380 mm(W) x 208 mm(D) x 600 mm(H) Weight 7 kg Replacement Filter Filter A / item : 115115 Pre-Filter Part #: 4521-0012-01 ※... -
Page 22: Product Warranty
PRODUCT WARRANTY The terms of the warranty are as follows. This product is manufactured under stringent quality control and inspections. Warranty void if product failure is a result of negligence or misuse by the consumer, shipping and service fees may be incurred even during the warranty period. The warranty must be presented upon bringing the product for service. - Page 23 2610-0169-00 Rev.00 Contact your local WWW.WINIX.COM/EU dealer for product related inquiries and customer service...
