- Page 1 User Manual WINIX AIR PURIFIER ZERO (AUS-1050AZBU) Model ˍ Please read and follow all safety rules and instructions Use & Care in this manual before operating. Guide ˍ The product warranty is printed on the back of this guide, so please keep it in a safe place for future use.
-
Page 2: Table Of Contents
CONTENTS 4-STAGE AIR PURIFICATION · · ············································ 3 CONTROLS ····························································· 4 WHERE TO USE ························································· 5 INSTALLING FILTERS ···················································· 6 SAFETY AND CAUTIONS · · ··············································· 8 INITIAL OPERATION ····················································· 9 AUTO & SLEEP ························································· 10 MANUAL & TIMER · · ···················································· 11 PLASMAWAVE ®... -
Page 3: 4-Stage Air Purification
4-STAGE AIR PURIFICATION Particle sensor PlasmaWave Light sensor Control Panel / Display Panel True HEPA lter Deodorization lter Pre- lter Power cord with plug (This product is suitable Front panel for 220-240V only.) Pre- lter/ Unit User Manual Deodorization lter/ True HEPA lter English ZERO... -
Page 4: Controls
CONTROLS Air Outlet Vent 소피아 1 PlasmaWave Indicator Timer Indicator Indicates whether If timer has been set, the LED light indicates the set PlasmaWave is enabled or disabled. time of operation. Mode Button Fan Speed Indicator Reset Button Press to cycle through and set Indicates the After replacing a lter, the desired mode of operation... -
Page 5: Where To Use
WHERE TO USE Allow 30 - 45 cm of space between TVs, radios, and other electronic products electromagnetic interference from certain electronics may cause product malfunction. Place indoors away from direct sun light direct exposure may cause product malfunction or failure. Only place on hard, flat surfaces flimsy or slanted surfaces may result in abnormal noise and vibrations. -
Page 6: Installing Filters
INSTALLING FILTERS This product comes with all required filters. The protective plastic wrap must be removed from the filter before use. ※ Operating the unit without removing the plastic wrap may result in product failure. ※ Unplug and make sure the unit is turned off before installing filter. Remove the front panel by grasping its ①... - Page 7 ※ Intervals between filter replacement may vary depending on environment. ※ For optimal use, Pre-filter can be cleaned once every 14 days which can extend the life of other filters. To purchase replacement Winix filters : contact our authorized distributor FILTER this unit ‘Ausclimate’...
-
Page 8: Safety And Cautions
SAFETY AND CAUTIONS Before operating this equipment, carefully read and follow these safety cautions Ensure filters are inserted before running unit running unit without filters can shorten the units life and cause electric shock or injury. Be sure foreign objects are NOT inserted into the vents on the unit objects can include pins, rods, and coins. -
Page 9: Initial Operation
INITIAL OPERATION Insert the power cord into an electrical ① outlet. Press the 'Power' button. ② ˍ During the first 30 seconds of power up, the Air Quality NOTE Indicator will cycle through Blue, Amber and Red colors. The Particle Sensors take approximately 30 seconds to gauge the air quality in the environment, after which normal operation will begin. -
Page 10: Auto & Sleep
AUTO & SLEEP 1. Auto Mode Enables auto operation based on the unit's air quality Particle Sensor. Press the Mode button to select Auto mode. ① ˍ The LED 'Auto' light will indicate when Auto mode is activated, and operation will begin. -
Page 11: Manual & Timer
MANUAL & TIMER 3. Manual Mode (setting fan speed) Users can opt to manually set the fan speed to Low, Medium, High, or Turbo. Press the Fan Speed button to set the ① desired fan speed. ˍ When Manual Mode is selected, Auto Mode is automatically NOTE disabled. -
Page 12: Plasmawave ® & Air Quality Indicator
PLASMAWAVE ® & AIR QUALITY INDICATOR 5. PlasmaWave ® ® By default, PlasmaWave is enabled whenever the unit is powered on. Press the Plasmawave button, when the unit ① is on, to enable or disable this feature. ˍ In Auto mode, as the indoor air quality improves, the fan NOTE speed will automatically be reduced to Low. -
Page 13: Filter Care
※ Intervals between filter replacement may vary depending on environment. ※ For optimal use, Pre-filter can be cleaned once every 14 days which can extend the life of other filters. To purchase replacement Winix filters : contact our authorized distributor FILTER this unit ‘Ausclimate’... - Page 14 ˍ Operating the unit without removing filters from plastic wrap may cause abnormal noise, deformation, or fire as a result of overheating. ˍ For optimal performance, only Winix filters should be used NOTICE with this unit. English ZERO...
- Page 15 FILTER CARE 4. Replacing Filters Insert the True HEPA Filter first, then the ① Deodorization filter. True HEPA lter Deodorization lter Insert the Pre-filter. ② Tabs ˍ Insert bottom tabs of the Pre-filter into the slots on either side of the lower part of the unit, then rotate upward to insert the upper tabs into the slots at the top Pre- lter...
- Page 16 FILTER CARE 6. Cleaning the filter Intervals between filter cleaning may vary depending on the air quality. Use a vacuum cleaner or soft brush to clean ① the Pre-filter. If it is excessively soiled, rinse in room temperature water. ˍ Do not use detergent or soap. ˍ...
-
Page 17: Particle Sensor Care
PARTICLE SENSOR CARE Particle Sensors Care For optimal performance of the Particle Sensor, which detects airborne dust and ultrafine particles, clean it every two months. Clean it more frequently when the unit is running in a place with high dust levels. Open the Particle Sensor cover. -
Page 18: Cleaning Care
CLEANING CARE 1. Cleaning the Exterior & Interior Wipe with a soft damp cloth using room ① temperature water. Afterwards, wipe it down with a clean dry cloth. ˍ To keep unit in peak condition, clean every 1-2 months. Open the front panel and clean the interior ②... -
Page 19: Frequently Asked Questions
FREQUENTLY ASKED QUESTIONS Problem Check / Actions to take ˍ Is the plug securely attached to the outlet? - Make sure the outlet has power going to it, and ensure the plug is secured. It does not turn on at all. ˍ... - Page 20 FREQUENTLY ASKED QUESTIONS Problem Check / Actions to take ˍ Is it being used in a place with a lot of smoke, dust, or odours? There is a strange - Clean the air intakes on either side and clean smell. the pre-filter.
-
Page 21: Unit Specifications
UNIT SPECIFICATIONS Model Name AUS-1050AZBU Power Voltage 220 - 240 V, 50 / 60 Hz Power Rate 35 W Recommended room 38.2 m capacity Weight 7 kg Dimensions 380 mm(W) x 208 mm(D) x 600 mm(H) Replacement Filter FILTER GI, item : 1712-0090-01 ※... -
Page 22: Safety Instructions
SAFETY INSTRUCTIONS Thank you for purchasing a Winix air purifier. This product is for household use only. IMPORTANT CAUTIONS FOR IMPORTANT PRECAUTIONS FOR USING YOUR AIR PURIFIER USING YOUR AIR PURIFIER WARNING : Follow the instructions in this ˍ Do not block the intake or outlet vents. -
Page 23: Product Warranty
PRODUCT WARRANTY Air Purifier Product Name AUS-1050AZBU Model Name Purchase Date Two (2) years Warranty period Place of purchase Place of purchase Tel. Address Customer Name Tel. ※ After purchase, be sure to complete all of the above information. English ZERO... - Page 24 2610-0209-00 Rev.00 Contact for product To expedite service, please specify the model name and number, the related inquiries and nature of the problem, your contact information, and your address. customer service Distributed by After sales and warranty enquiries, visit website or call 1800 122 100 Ausclimate Pty Ltd Website : www.ausclimate.com.au / www.winixaustralia.com.au...
