EMS ZITON RADIO LOOP MODULE Programming Manual page 17

• To enter the Battery Level Menu press the rotary control with the Battery Level text displayed.
The display will change to show the current Battery Level for the individual packs of each
device an example is shown below;
Available Options are;
Pack 1 OK (With full battery icon shown)
Pack 1 Warning (With half full battery icon shown)
Pack 1 Low (With empty battery icon shown)
Pack 1 Missing (With X shown)
Pack 2 OK (With full battery icon shown)
Pack 2 Warning (With half full battery icon shown)
Pack 2 Low (With empty battery icon shown)
Pack 2 Missing (With X shown)
Note: Turn the rotary control to view the status of all associated battery packs for a particular
device.
• The menu will timeout after 30 seconds or alternatively press the Back button to immediately
return to the previous Menu.
•
To enter the Signal Level Menu press the rotary control with the Signal Level text displayed.
The display will change to show the last Signal Level for the two channels used. The received
signal strength at the Ziton Radio Loop Module from the device is shown as an LI
therefore indicating the signal that has been sent from the device to the Radio Loop Module.
The LI Dev level is updated every poll (123 seconds). The forward signal strength received
at a device from the Radio Loop Module is shown as an LI
signal that has been sent from the Radio Loop Module to the device. The LI
updated every 6 hours or when requested manually by selecting the Manual Update Option
from the menu.
• An example display is shown below;
The signal levels shown range from 100 - 0 with 100 being the highest signal to 0 where no
signal is being seen, as shown below;
100 Shown indicates Good Signal Level
90 Shown indicates Good Signal Level
80 Shown indicates Good Signal Level
70 Shown indicates Good Signal Level
60 Shown indicates Good Signal Level
50 Shown indicates Medium Signal Level
The minimum recommend level is 50 points or above on each channel.
Note: Turn the rotary control to view the status of all associated signal levels for a particular
device.
•
The menu will timeout after 30 seconds or alternatively press the Back button to immediately
return to the previous Menu.
EMS Group Head Office, Technology House, Sea Street, Herne Bay, Kent CT6 8JZ, England
Tel: +44 (0) 1227 369570 Fax: +44 (0) 1227 369679 Email:
Ziton Radio Loop Module Programming Manual (Issue 7d) TSD022
Pack 1 OK
Ch1 LI Dev 100
Available Options are;
Ch1 LI Dev (With Levels 100 -0 displayed)
Ch2 LI Dev (With Levels 100 -0 displayed)
Ch1 LI Dev (With Levels 100 -0 displayed)
Ch2 LI Dev (With Levels 100 -0 displayed)
Dev level, therefore indicating the
40 Shown indicates Low Signal Level
30 Shown indicates Caution Signal Level
20 Shown indicates Caution Signal Level
10 Shown indicates Caution Signal Level
0 Shown indicates No Signal Level Received
enquiries@emsgroup.co.uk
Dev level,
Dev level is
