Ident – this menu shows the unique identification number for the device.
Software Version – This menu details the software version of the Radio Loop Module.
Legacy Mode – To ensure correct operation of devices reporting to the Control Panel, Legacy
Mode must be correctly selected.
Legacy Mode 'ON' is to be selected when the Ziton Radio Loop Module is connected to a ZP3
Panel.
Legacy Mode 'OFF' is to be selected when the Ziton Radio Loop Module is connected to a ZP2
(2010) Panel.

3.5 Radio Channels

This menu allows the two frequency channels currently used by the Radio Loop Module to be
viewed and also allows the channels used to be selected either manually or automatically. 32
channels are available for use on the system and these are as follows;
Ch1: 868.048 MHz
Ch2: 868.073 MHz
Ch3: 868.098 MHz
Ch4: 868.123 MHz
Ch5: 868.148 MHz
Ch6: 868.173 MHz
Ch7: 868.198 MHz
Ch8: 868.223 MHz

4.0 FRONT DISPLAY OF RADIO LOOP MODULE

• The front display of the Ziton Radio Loop Module will show the number of devices that are
allocated it, along with the total number of current alarm and fault conditions. The DEV field
shows the total number of devices allocated between 00-31. The AL field shows the amount of
devices currently with outstanding Alarms and Pre-alarms ranging between 00-31.
field shows the amount of devices currently with outstanding Faults ranging between 00-31.
An example display will show;

5.0 ACCESSING THE RADIO LOOP MODULES MENUS

• To access the Users menu's from the front display screen , follow the steps listed below:
• Press the rotary control. The display will change to show;
• The Menu structure can be viewed by scrolling through the menu by turning the rotary control.
Entry into the required menu is achieved by locating the required menu on the display and
pressing the rotary control.
seconds or by pressing the Radio Loop Modules back button.
EMS Group Head Office, Technology House, Sea Street, Herne Bay, Kent CT6 8JZ, England
Tel: +44 (0) 1227 369570 Fax: +44 (0) 1227 369679 Email:
Ziton Radio Loop Module Programming Manual (Issue 7d) TSD022
Ch9: 868.248 MHz
Ch10 868.273 MHz
Ch11: 868.298 MHz
Ch12: 868.323 MHz
Ch13: 868.349 MHz
Ch14: 868.374 MHz
Ch15: 868.399 MHz
Ch16: 868.424 MHz
DEV01 AL00 FT00
DEV01 AL00 FT00
Device Status
Exiting from a menu option is achieved automatically after 30
Ch17: 868.749 MHz
Ch18: 868.774 MHz
Ch19: 868.800 MHz
Ch20: 868.825 MHz
Ch21: 868.850 MHz
Ch22: 868.875 MHz
Ch23: 868.900 MHz
Ch24: 868.925 MHz
enquiries@emsgroup.co.uk
Ch25: 868.950 MHz
Ch26: 868.975 MHz
Ch27: 869.000 MHz
Ch28: 869.025 MHz
Ch29: 869.050 MHz
Ch30: 869.075 MHz
Ch31: 869.100 MHz
Ch32: 869.125 MHz
The FT
