EMS ZITON RADIO LOOP MODULE Programming Manual page 10

Pack 1 Missing – this indicates a battery from Pack 1 is missing.
on the device for continued reliable operation. This is represented by displaying an X symbol.
Pack 2 OK – this indicates a good battery voltage is present in Pack 2.
displaying a full battery icon.
Pack 2 Warning – this indicates the battery voltage is low in Pack 2 and is a 30 day warning
indication. The batteries must be changed on the device within 30 days for continued reliable
operation. This is represented by displaying a half full battery icon.
Pack 2 Low – this indicates the battery voltage is low in Pack 2 and is a 7 day warning
indication. The batteries must be changed on the device within 7 days for continued reliable
operation. This is represented by displaying an empty battery icon.
Pack 2 Missing – this indicates a battery from Pack 2 is missing.
on the device for continued reliable operation. This is represented by displaying an X symbol.
Signal Level – this menu when entered shows information on the two signalling channels used
by the Radio Loop Module in both directions, as the devices are bi-directional.
signal strength at the Radio Loop Module from the device is shown as an LI
therefore indicating the signal that has been sent from the device to the Radio Loop Module. The
LI Dev level is updated on every poll response (123 seconds). The forward signal strength
received at a device from the Radio Loop Module is shown as an LI
indicating the signal that has been sent from the Radio Loop Module to the device. The LI
level is updated every 6 hours or when requested manually by selecting the Manual Update
Option from the menu.
Ch 1 LI Dev – this indicates the received signal strength at the Radio Loop Module from the
device on the first frequency channel used by the system.
indicate the levels, a table of which is shown at the end of this section.
Ch 2 LI Dev – this indicates the received signal strength at the Radio Loop Module from the
device on the second frequency channel used by the system. A level from 100 -0 is shown to
indicate the levels, a table of which is shown at the end of this section.
Ch 1 LI Dev – this indicates the forward signal strength received at the device from the Radio
Loop Module on the first frequency channel used by the system. A level from 100 -0 is shown to
indicate the levels, a table of which is shown at the end of this section.
Ch 2 LI Dev – this indicates the forward signal strength received at the device from the Radio
Loop Module on the second frequency channel used by the system. A level from 100 -0 is shown
to indicate the levels, a table of which is shown at the end of this section.
The individual devices have signal levels available for both of their operating channels (Ch1 and
Ch2) and also for both directions (Radio Loop Module to Device (LI
Loop Module (LI
100 - 0 with 100 being the highest signal to 0 where no signal is being seen, as shown below;
100
90
80
70
60
50
40
30
20
10
0
