Icom ID-800H Service Manual page 37

[MAIN UNIT]
REF ORDER
NO. NO.
C280 4030006970 S.CER C1608 CH 1H 060D-T
C281 4030006860 S.CER C1608 JB 1H 102K-T
C282 4030011170 S.CER GRM31M2C2H180JV01L
C283 4030011600 S.CER C1608 JB 1E 104K-T
C284 4030011140 S.CER GRM31M2C2H120JV01L
C285 4030011220 S.CER GRM31M2C2H360JV01L
C286 4030006860 S.CER C1608 JB 1H 102K-T
C288 4030011090 S.CER GRM31M2C2H7R0DV01L
C289 4030011190 S.CER GRM31M2C2H270JV01L
C290 4030009500 S.CER C1608 CH 1H 0R5B-T
C291 4030006860 S.CER C1608 JB 1H 102K-T
C292 4030011110 S.CER GRM31M2C2H9R0DV01L
C293 4030006860 S.CER C1608 JB 1H 102K-T
C294 4030006860 S.CER C1608 JB 1H 102K-T
C295 4030011070 S.CER GRM31M2C2H5R0CY21L
C296 4030009530 S.CER C1608 CH 1H 030B-T
C297 4030008920 S.CER C1608 JB 1H 473K-T
C298 4030009540 S.CER C1608 CH 1H 1R5B-T
C299 4030011090 S.CER GRM31M2C2H7R0DV01L
C300 4030006860 S.CER C1608 JB 1H 102K-T
C301 4030009920 S.CER C1608 CH 1H 050B-T
C302 4030009560 S.CER C1608 CH 1H R75B-T
C303 4030007060 S.CER C1608 CH 1H 270J-T
C304 4030009540 S.CER C1608 CH 1H 1R5B-T
C305 4030011170 S.CER GRM31M2C2H180JV01L
C306 4030011040 S.CER GRM31M4C2H2R0CY21L
C310 4030008920 S.CER C1608 JB 1H 473K-T
C311 4030011600 S.CER C1608 JB 1E 104K-T
C312 4030017490 S.CER C1608 JB 1A 105K-T
C501 4030011600 S.CER C1608 JB 1E 104K-T
C502 4510006021 ELE 16 ME 2200 HC
C503 4030006860 S.CER C1608 JB 1H 102K-T
C504 4030009590 S.CER C2012 JF 1C 225Z-T
C505 4030006900 S.CER C1608 JB 1H 103K-T
C506 4030007090 S.CER C1608 CH 1H 470J-T
C507 4030012610 S.CER C2012 JB 1C 474K-T
C508 4030006900 S.CER C1608 JB 1H 103K-T
C509 4030007090 S.CER C1608 CH 1H 470J-T
C510 4030006860 S.CER C1608 JB 1H 102K-T
C511 4030007070 S.CER C1608 CH 1H 330J-T
C512 4030006860 S.CER C1608 JB 1H 102K-T
C513 4030011600 S.CER C1608 JB 1E 104K-T
C514 4030009910 S.CER C1608 CH 1H 040B-T
C515 4030006860 S.CER C1608 JB 1H 102K-T
C516 4030006860 S.CER C1608 JB 1H 102K-T
C517 4030007090 S.CER C1608 CH 1H 470J-T
C519 4030008900 S.CER C1608 JB 1H 333K-T
C520 4030007050 S.CER C1608 CH 1H 220J-T
C521 4030011600 S.CER C1608 JB 1E 104K-T
C522 4030006860 S.CER C1608 JB 1H 102K-T
C523 4030006860 S.CER C1608 JB 1H 102K-T
C524 4030007090 S.CER C1608 CH 1H 470J-T
C525 4550007080 S.TAN TEESVA 1C 106M8R
C526 4030006860 S.CER C1608 JB 1H 102K-T
C527 4030012610 S.CER C2012 JB 1C 474K-T
C528 4030007090 S.CER C1608 CH 1H 470J-T
C529 4510007310 S.ELE 16 CV 10 BS
C531 4550007080 S.TAN TEESVA 1C 106M8R
C532 4550007080 S.TAN TEESVA 1C 106M8R
C533 4030008910 S.CER C1608 JB 1H 393K-T
C534 4030008910 S.CER C1608 JB 1H 393K-T
C535 4030011600 S.CER C1608 JB 1E 104K-T
C536 4030011600 S.CER C1608 JB 1E 104K-T
C537 4030017490 S.CER C1608 JB 1A 105K-T
C538 4510007280 S.ELE 50 CV 2R2 BS
C539 4030006860 S.CER C1608 JB 1H 102K-T
C540 4030006860 S.CER C1608 JB 1H 102K-T
C542 4030011600 S.CER C1608 JB 1E 104K-T
C544 4030011600 S.CER C1608 JB 1E 104K-T
C545 4030006900 S.CER C1608 JB 1H 103K-T
C546 4550006760 S.TAN TEESVB21A336M8R
C547 4030017490 S.CER C1608 JB 1A 105K-T
C548 4030008890 S.CER C1608 JB 1H 273K-T
C549 4510007310 S.ELE 16 CV 10 BS
C550 4030006860 S.CER C1608 JB 1H 102K-T
C551 4030011600 S.CER C1608 JB 1E 104K-T
C552 4030006900 S.CER C1608 JB 1H 103K-T
C553 4030017490 S.CER C1608 JB 1A 105K-T
C554 4030011600 S.CER C1608 JB 1E 104K-T
C555 4030008880 S.CER C1608 JB 1H 223K-T
C556 4030011600 S.CER C1608 JB 1E 104K-T
C557 4030008650 S.CER C1608 JB 1H 332K-T
C558 4030006860 S.CER C1608 JB 1H 102K-T
C559 4030008650 S.CER C1608 JB 1H 332K-T
C560 4030012610 S.CER C2012 JB 1C 474K-T
C561 4030006860 S.CER C1608 JB 1H 102K-T
C562 4030006860 S.CER C1608 JB 1H 102K-T
C563 4030008920 S.CER C1608 JB 1H 473K-T
C564 4030011810 S.CER C1608 JB 1A 224K-T
C566 4510007310 S.ELE 16 CV 10 BS
C567 4510008130 S.ELE 16 CV 220 BS
C568 4510008140 S.ELE 10 CV 470 BS
DESCRIPTION M.
LOCATION
T
T 90.5/87.2
T 85.9/102.2
B 63.3/92.3
T 94.1/96.8
T 98.4/111.7
B 57.1/94.6
T 101.5/100.9
T 103.9/111.7
T 78.3/97.3
T 115.9/79.1
T 109.7/102.2
T 58.9/92.4
T 117.3/83.6
T 114.2/103.5
T 87.4/87.5
T 64.7/97.2
B 111.9/94.7
T 117.3/104.5
T 61.9/91.8
B 91.9/101
B 111.9/97.3
T 80.9/101.8
B 111.9/99.9
B 79.5/110.1
B 94.4/99.2
T 56.9/23.3
T 59.6/20.7
B 56.3/17.1
B 108.7/25.3
T 34.9/96.7
B 114.9/13.4
B 107.6/19.8
B
B 10.2/52.7
B 114.3/18.2
B 118.8/21.5
B
B 116/16.9
T
T 26.8/83.1
B 113.3/16.1
B
T 26.8/81.7
T
B 109.9/12
B 119.7/15.6
B
B 108.5/13.2
T
B
T 13.4/42.4
B
B
B 104.7/5.7
T
T
T 13.1/51.1
T
T
T 122.2/37
T
T 16.8/14.2
T 25.1/14.1
T 99.5/37.5
T 25.4/18.5
B 101.1/28.9
T
B 92.8/24.9
T
T 20.9/22.3
T 12.5/64.3
T 27.7/58.8
T 88.3/31.3
T 11.9/56.8
T 16.2/48.9
T 15.3/24.9
T 16.2/52.9
T 18.9/52.9
T 31.8/55.7
T 18.9/48.9
T 116.8/38
T 17.6/46.3
T
T
T
T
T
T
T 18.2/84.5
T 10.3/86.6
[MAIN UNIT]
H/V REF ORDER
NO. NO.
78.7/95 C569 4030011600 S.CER C1608 JB 1E 104K-T
C570 4030011600 S.CER C1608 JB 1E 104K-T
C571 4030011600 S.CER C1608 JB 1E 104K-T
C572 4030007090 S.CER C1608 CH 1H 470J-T
C573 4030017490 S.CER C1608 JB 1A 105K-T
C574 4510007310 S.ELE 16 CV 10 BS
C575 4510007310 S.ELE 16 CV 10 BS
C577 4550006170 S.TAN ECST1AY225R
C579 4030006860 S.CER C1608 JB 1H 102K-T
C580 4030006860 S.CER C1608 JB 1H 102K-T
C581 4030006860 S.CER C1608 JB 1H 102K-T
C582 4550006170 S.TAN ECST1AY225R
C584 4030006860 S.CER C1608 JB 1H 102K-T
C585 4030006860 S.CER C1608 JB 1H 102K-T
C586 4030011730 S.CER GRM31M2C2H101JV01L
C587 4030011600 S.CER C1608 JB 1E 104K-T
C588 4030006860 S.CER C1608 JB 1H 102K-T
C589 4030006860 S.CER C1608 JB 1H 102K-T
C590 4030006860 S.CER C1608 JB 1H 102K-T
C591 4030006860 S.CER C1608 JB 1H 102K-T
C592 4030011810 S.CER C1608 JB 1A 224K-T
C593 4030006860 S.CER C1608 JB 1H 102K-T
C594 4030006860 S.CER C1608 JB 1H 102K-T
C595 4030006860 S.CER C1608 JB 1H 102K-T
C596 4030006860 S.CER C1608 JB 1H 102K-T
C597 4030007010 S.CER C1608 CH 1H 100D-T
C598 4030006860 S.CER C1608 JB 1H 102K-T
C599 4030009910 S.CER C1608 CH 1H 040B-T
C600 4030006860 S.CER C1608 JB 1H 102K-T
C601 4030006860 S.CER C1608 JB 1H 102K-T
C602 4030006860 S.CER C1608 JB 1H 102K-T
C603 4030006860 S.CER C1608 JB 1H 102K-T
C604 4030006860 S.CER C1608 JB 1H 102K-T
C605 4030006860 S.CER C1608 JB 1H 102K-T
3.3/8.6 C606 4030007130 S.CER C1608 CH 1H 101J-T
C607 4030007130 S.CER C1608 CH 1H 101J-T
C608 4030006860 S.CER C1608 JB 1H 102K-T
C609 4030006860 S.CER C1608 JB 1H 102K-T
4/13.9 C610 4030006980 S.CER C1608 CH 1H 070D-T
C611 4030006860 S.CER C1608 JB 1H 102K-T
24.5/9.4 C612 4030006900 S.CER C1608 JB 1H 103K-T
C616 4030007090 S.CER C1608 CH 1H 470J-T
C617 4030007090 S.CER C1608 CH 1H 470J-T
21.3/6.5 C618 4030007090 S.CER C1608 CH 1H 470J-T
C619 4030007090 S.CER C1608 CH 1H 470J-T
83.9/6.7 C620 4030006860 S.CER C1608 JB 1H 102K-T
C621 4030006860 S.CER C1608 JB 1H 102K-T
C623 4030006860 S.CER C1608 JB 1H 102K-T
9/42.3 C624 4030006860 S.CER C1608 JB 1H 102K-T
C625 4030006860 S.CER C1608 JB 1H 102K-T
20.3/6.8 C626 4030006860 S.CER C1608 JB 1H 102K-T
99.5/3 C627 4030006860 S.CER C1608 JB 1H 102K-T
C628 4030006860 S.CER C1608 JB 1H 102K-T
13.4/2.9 C629 4030006860 S.CER C1608 JB 1H 102K-T
41.6/80 C630 4030006860 S.CER C1608 JB 1H 102K-T
C632 4030007090 S.CER C1608 CH 1H 470J-T
90.7/8.4 C633 4030007140 S.CER C1608 CH 1H 121J-T
47.9/82 C634 4030007140 S.CER C1608 CH 1H 121J-T
C635 4030006860 S.CER C1608 JB 1H 102K-T
8.6/13.9 C636 4030011810 S.CER C1608 JB 1A 224K-T
10.4/16 C637 4030011810 S.CER C1608 JB 1A 224K-T
C638 4030006860 S.CER C1608 JB 1H 102K-T
15/15.7 C639 4030006860 S.CER C1608 JB 1H 102K-T
C640 4030006860 S.CER C1608 JB 1H 102K-T
C641 4030006860 S.CER C1608 JB 1H 102K-T
C642 4030006860 S.CER C1608 JB 1H 102K-T
C643 4030006860 S.CER C1608 JB 1H 102K-T
C644 4030011810 S.CER C1608 JB 1A 224K-T
31.1/3.1 C645 4030011810 S.CER C1608 JB 1A 224K-T
C646 4030006860 S.CER C1608 JB 1H 102K-T
9.3/23.3 C647 4030006860 S.CER C1608 JB 1H 102K-T
C648 4030006860 S.CER C1608 JB 1H 102K-T
C649 4030006860 S.CER C1608 JB 1H 102K-T
C650 4030006860 S.CER C1608 JB 1H 102K-T
C651 4030006860 S.CER C1608 JB 1H 102K-T
C652 4030006860 S.CER C1608 JB 1H 102K-T
C654 4030007090 S.CER C1608 CH 1H 470J-T
C655 4030007090 S.CER C1608 CH 1H 470J-T
C656 4030006860 S.CER C1608 JB 1H 102K-T
C657 4030006860 S.CER C1608 JB 1H 102K-T
C658 4030006860 S.CER C1608 JB 1H 102K-T [USA] only
C660 4030006860 S.CER C1608 JB 1H 102K-T
C661 4030006860 S.CER C1608 JB 1H 102K-T
C662 4030006860 S.CER C1608 JB 1H 102K-T
3.2/61 C663 4030006860 S.CER C1608 JB 1H 102K-T
32.2/6.7 C664 4030007090 S.CER C1608 CH 1H 470J-T
33/3.1 C665 4030007090 S.CER C1608 CH 1H 470J-T
8.7/67.1 C666 4030007010 S.CER C1608 CH 1H 100D-T
10/68.3 C667 4030007010 S.CER C1608 CH 1H 100D-T
9/33.5 C668 4030007010 S.CER C1608 CH 1H 100D-T
C669 4030007010 S.CER C1608 CH 1H 100D-T
C670 4030006860 S.CER C1608 JB 1H 102K-T
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
