Travel Trailer Operation

Unhitching Instructions

NOTE: Prior to unhitching from the tow vehicle, ensure unit is parked on a level surface and chock the tires
of the unit.
1.
Push "ON/OFF" button (Fig. 1K) to turn system "ON" (green light).
2. Push "UP" (Fig. 1A) or "DOWN" arrow (Fig. 1B) to scroll through features to "MANUAL MODE" in
display.
3.
Push "ENTER" (Fig. 1C).
4. Push "FRONT" button (Fig. 1G) to extend front jacks to the ground until the trailer is unhitched from
the tow vehicle.
NOTE: The Power Tongue Jack should ONLY be used when storing the trailer.

Auto Level

NOTE: The Power Tongue Jack MUST be retracted prior to starting auto level sequence (Fig. 3 shows the
LCD alert).
1.
After unhitching from tow vehicle press "AUTO LEVEL" (Fig. 1F).
NOTE: Pressing any button during an Auto Level sequence will abort the auto leveling cycle.
NOTE: In order for hitch recognition feature to function, the auto level sequence MUST be started with the
front of the unit above level.

Auto Level Sequence

1.
Front jacks retract, lowering the front of the unit below level, stopping, then lifting the front end to
level the unit front to back.
2. The rear left side leveling jack extends and raises the roadside of the unit.
3.
The rear right side leveling jack extends and raises the curbside of the unit, beginning side to side
leveling.
4. The front jacks extend to complete the leveling cycle.
NOTE: Additional left to right or front to back leveling may occur if the controller deems necessary.
NOTE: If the auto level sequence does not happen as stated above, check to ensure proper manual function
in all zones.

Hitch Recognition

1.
Turn on touch pad.
2. Press the left and right buttons simultaneously (Fig. 1H and 1I).
3.
The front of the unit will raise to the height where the auto level sequence was started.
Rev: 04.05.2018
Fig. 3
Page 6
Level-Up Towable Owner's Manual
