USE, INSTALLATION AND MAINTENANCE
INSTRUCTIONS FOR BUILT-IN HOT PLATES
Dear Customer
Thank you for purchasing a Blanco Cooktop.
You will find that the clean lines and modern look of your Blanco Cooktop blends perfectly with your kitchen
décor. It is easy to use and performs to a high standard.
Blanco also makes a range of products that will enhance your kitchen such as ovens, rangehoods,
dishwashers, microwaves, sinks and taps.
There are models to complement your new Blanco Cooktop.
Of course we make every effort to ensure that our products meet all your requirements, and our Customer
Relations department is at your disposal, to answer your questions and to listen to all your suggestions (see
back cover of manual).
Please complete the warranty section of this manual and keep your receipt as proof of purchase. Retain all
documents relating to the purchase of this products.
Blanco is committed to providing increasingly efficient products that are easy to use, respect the environment
and are attractive and reliable.
BLANCO
We ask that you carefully read the instructions within this booklet to enable you to obtain quality results from the outset.
The appliance must be installed only by an authorised person in compliance with the instructions provided. The manufacturer
declines all responsibility for improper installation which may harm persons and animals and damage property.
The appliance must be used for the purpose for which it was expressly designed. Any other use (eg heating rooms) is considered
to be improper and consequently dangerous. The manufacturer declines all responsibility for damage resulting from improper
and irresponsible use.
The manufacturer shall not be held responsible for any inaccuracies in this handbook due to printing or transcription errors.
The designs in the figures are purely indicative.
The manufacturer also reserves the right to make any modifications to the products as may be considered necessary, useful or in
the interests of the user, without jeopardizing the main functional and safety features on the products themselves.
If your cooktop requires service, please contact the Blanco customer service center.
MODEL: CG604WXFFCP
60 CM, 4 BURNER GAS COOKTOP
(SIDE CONTROL)
COD. 01099GGB9423 - 22.10.2015
Advertisement
Table of Contents
Related Manuals for Blanco CG604WXFFCP
Summary of Contents for Blanco CG604WXFFCP
- Page 1 Dear Customer Thank you for purchasing a Blanco Cooktop. You will find that the clean lines and modern look of your Blanco Cooktop blends perfectly with your kitchen décor. It is easy to use and performs to a high standard.
- Page 2 DESCRIPTION OF THE HOT PLATES Natural U-LPG Rapid gas burner 12.0 MJ 10.4 MJ Semi-rapid gas burner 7.1 MJ 6.3 MJ Auxiliary gas burner 4.1 MJ 3.6 MJ Trivet 2 burner Burner 3 control knob Burner 1 control knob 10 Burner 2 control knob (right) 11 Burner 2 control knob (left) 14.5 MJ 11.4 MJ...
- Page 3 1) BURNERS - When the pan comes to the boil, set the knob to the reduced rate position (small flame fig. 1). A diagram is screen-printed above each knob on - Always place a lid on the pans. the front panel. This diagram indicates to which burner the knob in question corresponds.
- Page 4 WARNINGS AND ADVICE FOR THE USER: use of a gas cooking appliance produces heat and moisture in the room in which it is installed. The room must therefore be well ventilated by keeping the natural air vents clear (fig. 3) and by activating the mechanical aeration device (suction hood or electric fan fig.
-
Page 5: Care And Maintenance
CLEANING IMPORTANT: - Do not force the taps if they are difficult open or close. Contact the technical assistance always disconnect the appliance from the gas service for repairs. and electricity mains before carrying out any - Do not use a steam to cleaner to clean this cleaning operation. -
Page 6: Installation
INSTALLATION TECHNICAL INFORMATION Any adjoining wall surface situated within 200 mm FOR THE INSTALLER from the edge of any hob burner must be a suitable This appliance shall be installed only by non-combustible material for a height of 150 mm for authorised personnel and in accordance with the entire length of the hob. -
Page 7: Gas Connection
INSTALLATION 5) GAS CONNECTION Liquified Petroleum Gas In a LPG installation the gas regulation is made at The gas connection is located in the rear and on the the gas cylinder and regulation at the appliance is underside of the appliance 100 mm from the right not required. - Page 8 ADJUSTMENTS 7) TAPS Always disconnect the appliance from the electricity main before making any adjustments. Our taps are suitable for all gas, they are male All seals must be replaced by the technician at conical type. the end of any adjustments or regulations. “Reduced rate”...
- Page 9 PROCEDURE LPG CONVERSION PROCEDURE Appliance models: Gas stainless steel hotplate Appliance models: Gas stainless steel hotplate models: models: CG604WXFFCP 4 Burners CG604WXFFCP 4 Burners 1. Remove each burner cap and burner skirt. 1. Remove each burner cap and burner skirt.
-
Page 10: Replacing The Injectors
CONVERSIONS 10) REPLACING THE INJECTORS affix the label corresponding to the new gas regulation on the appliance instead of the already The burners can be adapted to different types of gas existing one. This label is supplied in the packet by installing injectors suited to the type of gas containing the spare injectors. - Page 11 SERVICING Always turn off the electrical ignition before Greasing the taps (see fig. 17 - 18) proceeding with any servicing operation. If a tap becomes stiff to operate, it must be Servicing should be carried out only by immediately greased in compliance with the authorised personnel.
- Page 12 SERVICING CABLE TYPES AND SECTIONS TYPE OF TYPE OF SINGLE - PHASE HOT PLATE CABLE POWER SUPPLY H05 RR - F Section 3 X 0.75 mm Gas hot plate ATTENTION!!! If the power supply cable is replaced, the installer should leave the ground wire longer than the phase conductors (fig.
-
Page 16: Technical Assistance And Spare Parts
Our Warranty (which is subject to the conditions below) covers rectification free of charge of any fault arising from defective materials or components, or faulty workmanship. The product will be repaired or replaced at the option of Blanco, and all costs of installation, removal, cartage, freight travelling expenses and insurance are to be paid by the customer.
