Overview
two user-input push buttons
one Wakeup-input push button
one reset push button
two DataFlash SD/MMC card slots
four expansion connectors (PIOA, PIOB, PIOC, IMAGE SENSOR)
one BGA-like EBI expansion footprint connector
one Lithium Coin Cell Battery Retainer for 12 mm cell size
1-2
6413C–ATARM–18-Feb-09
AT91SAM9G20-EK Evaluation Board User Guide
