ABOUT YOUR SYSTEM

OUTSIDE

1
1. Ventilation
2. Lid
3. Emergency Stop Button
4. Laser Signal Light
5. Key Locked Front Panel
6. Three Position Touchscreen
7. Exhaust
8. Input panel
2
3 4
5
6
11
12
1
10
13
14
15
16
9. Key Locked Rear Panel
10. Key Locked Side Panel
11. Accessory Box Connection
12. Air Assist Port (If Applicable)
13. Ethernet Port
14. On/Off Switch
15. Fuse Holder
16. Power Inlet
7
8
9
