OPTICS
1. Mirror #1
2. Combiner Mirror
3. Mirror #2
TABLE AND TABLE ELEVATOR ASSEMBLY
2
3
1. Work table
2. X axis ruler
3. Y axis ruler
4. Table Leadscrew Assembly
5. Z Axis Motor
6. Z Axis Belt
4
5
1
5
4
6
3
4. Mirror #3
5. Lens
9
8
10
11
7. Table Mount
8. Leadscrew Mounts
9. Z Axis Leadscrew Bearing
10. Z Axis Leadscrew
11. Z Axis Pulley
2
1
7
