9. TRACK OUTPUTS L/M(mono)/R Audio outputs for Track 1–4. Use L output for
summed mono audio. Use either 1/4" mono phone plug (unbalanced connection) or 1/4"
Tip/Ring/Sleeve phone plug (balanced connection).
10. OUTPUT L/R Main audio outputs. Use either 1/4" mono phone plug (unbalanced
connection) or 1/4" Tip/Ring/Sleeve phone plug (balanced connection).
11. HEADPHONES Audio output for headphones. Use 1/4" Tip/Ring/Sleeve phone plug.

2. GETTING STARTED WITH DIGITONE KEYS

2.1 SETTING UP AND STARTING

Make sure you place the Digitone Keys on a stable support, with sufficient space for the
cables. Switch off all devices before you connect the Digitone Keys to other devices.
1. Plug the supplied DC adapter into a power outlet and connect the small plug to the 12 V
DC In on the Digitone Keys.
2. Connect OUTPUT L/R from the Digitone Keys to your mixer or amplifier.
3. To control the Digitone Keys from a computer, connect a USB cable between the com-
puter and the USB connector of the Digitone Keys.
4. If you want to use MIDI to control the Digitone Keys, connect the MIDI OUT port of the
device you wish to use as a controller to the MIDI IN port of the Digitone Keys. If you
want to use Digitone Keys to control other devices using MIDI, connect the MIDI OUT
port of the Digitone Keys to the MIDI IN port of the of the device you want to control.
5. Connect an audio source to INPUT L/R or via USB if you want to process audio from
external sources.
6. Switch on all units. Press the POWER switch on the Digitone Keys to switch it on.

2.2 CHANGING SOUNDS

Press [SOUND BROWSER] and then use the LEVEL/DATA knob to scroll through the list
of Sounds. Press LEVEL/DATA to load a Sound to the active track.
