- Page 1 Original instructions SWX C/D ... 10 ... 14 ... 18 ... 22 ... 26 ... 30 ... 34 ... 38 ... 42 ... 46...
- Page 2 SWX C/D SWX C/D ØI ØI [mm] ØI SWX C12/D13 R3/4" SWX C22/D23 R3/4" Electrical installation 230V~ Terminal box 0,85 m cable...
- Page 3 SWX C/D Accessories HxWxD Type [mm] SWXCDFT1 SWXC12/D13 515x455x20 SWXCDFT2 SWXC22/D23 620x590x20 SWXCDFT Controls SWX C Type RSK-nr NRF-nr HxWxD (SE) (NO) [mm] SWXRT35 175x150x100 RE1,5* 673 09 56 200x105x105 RE3* 672 70 31 85 021 41 200x105x105 SWXRT35 RE1,5/3/RE7 RE7* 672 70 32 85 021 42...
- Page 4 SWX C/D Wiring diagrams SWX C/D Internal SWXC -12, -22 SWXD -13, -23 BK BU WT RD SWX C Control by thermostat only SWXC -12, -22 SWXC -12, -22 SD20* SD20* TVV20/25* TVV20/25* BK BU WT RD BK BU WT RD *) Note! Only for mounting outside corrosive environment.
- Page 5 SWX C/D 5-step control of airflow only SWXC -12, -22 SWXC -12, -22 BK BU WT RD BK BU WT RD RE1,5/3/5* *) Note! Only for mounting outside corrosive environment. 230V~ Thermostat and 5-step control SD20* SWXC -12, -22 SWXC -12, -22 SD20* TVV20/25* TVV20/25*...
- Page 6 SWX C/D SWX D Control by thermostat only SD20 SWXD -13, -23 SWXD -13, -23 SD20 TVVS20/25 TVVS20/25 KRT(V) 19(00) 16A 230V~ /10A 400V~ °C BK BU WT RD BK BU WT RD 3 2 1 230V~ 5-step control of airflow only SWXD -13, -23 SWXD -13, -23 BK BU WT RD...
- Page 7 SWX C/D Thermostat and 5-step control SD20 SWXD -13, -23 SWXD -13, -23 SD20 TVVS20/25 TVVS20/25 KRT(V) 19(00) 16A 230V~ /10A 400V~ °C BK BU WT RD BK BU WT RD 3 2 1 RE1,5/3/5 230V~...
- Page 8 SWX C/D SWX C ∆t* Heat Airflow Airflow Sound Water Voltage Amperage Weight output* level* throw volume* [kW] [m³/h] [m³/s] [dB(A)] [°C] [kg] SWXC12 20 2160 230V~ SWXC22 37 4300 230V~ 1,35 SWX D ∆t* Heat Airflow Airflow Sound Water Voltage Amperage Weight...
- Page 9 SWX C/D Output charts water SWX C Incoming / outgoing water temperature 90/70 °C Air temp. in = +5 °C Air temp. in = +15 °C Type Airflow Output Air temp. Water flow Pressure Output Air temp. Water Pressure drop flow drop [m³/h]...
- Page 10 SWX C/D Assembly and operating instructions General Instructions • Wall bracket supplied for mounting of the Read these instructions carefully before fan heater on the wall for a horizontal air installation and use. Keep this manual for stream, or in the ceiling for a vertical air future reference.
- Page 11 SWX C/D Fitting the wall bracket 1. Remove the eight screws indicated by the 2. Install the brackets with the holes toward arrows in picture A. the fan motor, as shown in picture B. 3. The fan heater may be mounted with the 4.
- Page 12 SWX C/D Connection of heating coil Maintenance The installation must be carried out by an To ensure performance and reliabilty of authorised installer. By turning the fan heater, the unit, inspection and cleaning should be pipe connections are possible on both sides. carried out reguarly.
- Page 13 SWX C/D Cleaning Safety The interval between each cleaning depends • Ensure that the area around the intake on the environment the fan heater is used in. is kept free from material which could Dust on the fan protective grille and on the prevent the air flow through the appliance.
- Page 14 Main offi ce Frico AB Tel: +46 31 336 86 00 Box 102 SE-433 22 Partille mailbox@frico.se Sweden www.frico.se For latest updated information and information about your local contact: www.frico.se...
