Summary of Contents for Frico SWXH13
- Page 1 Original instructions SWX H ... 8 ... 12 ... 16 ... 20 ... 24 ... 28 ... 32 ... 36 ... 40 ... 44...
- Page 2 SWX H ØI [mm] ØI ø22 SWXH13 SWXH23 ø28 Electrical installation 230V~ Terminal box 0,85 m cable...
- Page 3 SWX H Accessories HxWxD Type [mm] SWXCDFT1 SWXH13 515x455x20 SWXCDFT2 SWXH23 620x590x20 SWXCDFT Controls SWX H Type RSK-nr NRF-nr HxWxD (SE) (NO) [mm] 175x150x100 SWXRT70 RE1,5* 200x105x105 673 09 56 RE3* 672 70 31 85 021 41 200x105x105 SWXRT70 RE1,5/3/RE7...
- Page 4 SWX H Wiring diagrams SWX H Internal SWXH -13 -23 SWXC -12, -22 SWXD -13, -23 BK BU WT RD Control by thermostat only SWXH -13, -23 SWXH -13, -23 SD20* SD20* TVV20/25* TVV20/25* BK BU WT RD BK BU WT RD *) Note! Only for mounting outside hot environments >50 °C.
- Page 5 SWX H 5-step control of airflow only SWXH -13, -23 SWXH -13, -23 BK BU WT RD BK BU WT RD RE1,5/3/5* *) Note! Only for mounting outside hot environments >50 °C. 230V~ Thermostat and 5-step control SD20* SWXH -13, -23 SWXH -13, -23 SD20* TVV20/25*...
- Page 6 [kW] [m³/h] [m³/s] [dB(A)] [°C] [kg] SWXH13 12 1830 230V~ SWXH23 23 3870 230V~ 1,35 ) Applicable at water temperature 80/60 °C, air temperature, in +40 °C. ) Conditions: Distance to the unit 5 metres. ) ∆t = temperature rise of passing air at maximum heat output.
- Page 7 SWX H Output charts water SWX H...
- Page 8 Read these instructions carefully before The fan heater is available in two sizes, installation and use. Keep this manual for SWXH13 and SWXH23. They have future reference. been especially developed to heat the The product may only be used as set out in air in environments with high ambient the assembly and operating instructions.
- Page 9 SWX H Fitting the wall bracket 1. Remove the eight screws indicated by the 2. Install the brackets with the holes toward arrows in picture A. the fan motor, as shown in picture B. 3. The fan heater may be mounted with the 4.
- Page 10 During inspection the power supply must arrows in picture E. always be disconnected. Ø22 connection on SWXH13 and ø28 The fan heater is equipped with inspection connection on SWXH23. If compression hatches with quick-release locks. Open the fittings are installed, check that they can quick-release locks according to picture F.
- Page 11 SWX H Cleaning Safety The interval between each cleaning depends • Ensure that the area around the intake on the environment the fan heater is used in. is kept free from material which could Dust on the fan protective grille and on the prevent the air flow through the appliance.
- Page 12 Main offi ce Frico AB Tel: +46 31 336 86 00 Box 102 SE-433 22 Partille mailbox@frico.se Sweden www.frico.se For latest updated information and information about your local contact: www.frico.se...
