TEMPERATURE MEASUREMENTS

WARNING: The supplied thermocouple range is limited and does not measure over
the entire temperature range of the meter.
1. Set the function switch to the TEMP position.
2. Press the M button to indicate
display.
3. Connect the Type-K thermocouple to the
thermocouple-to-banana adaptor.
4. Connect the adaptor's negative lead to the COM
jack.
5. Connect the adaptor's positive lead to the positive
jack.
6. Touch the Type-K tip to the part under test or leave
in open air.
7. Read the temperature on the display. Use the M
button to select

NCV NON-CONTACT (EF) VOLTAGE MEASUREMENTS

WARNING: Check the NCV function on a known live circuit before testing on a circuit
of unknown status.
1. Set the function switch to the
'NCV' icons will appear.
2. The non-contact voltage detection sensor is located at the
top of the meter. Place the sensor near the source of
voltage.
3. When the meter detects voltage it will audibly beep, the
display will blink red, and dashes will appear. The number of
dashes is proportional to the strength of the voltage source
as is the periods between audible beeps. Note that the
meter flashes red with each audible beep.
o
C or
o o
C or F.
o
F on the
position. The 'EF' and
16 MM750W-en-GB_v1.1 12/18
