- Page 1 Issue 3 Description: Robinhood 60cm Built-in Oven 9 Function with Digital Timer OBD609K65SS Model Numbers:...
-
Page 2: Warning And Safety Information
Warning and safety information This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. -
Page 3: Installing The Built In Oven
Installing the built in oven Important: the power supply to the appliance must be turned off before any adjustments or maintenance work. Installation of Built-in Oven To ensure the proper working order of the built-in appliance, the kitchen unit must be of a suitable size. In accordance with safety standards, once the appliance has been mounted, there must be no possible contact with electrical parts. - Page 4 Installing the built in oven - continued Electric connection This oven must be connected to a 220-240V 50Hz power supply. It is earthed via the power cable and plug. Before carrying out the connection to the power supply, the voltage rating of the appliance (stamped on the appliance identification plate) must be checked for correspondence to the available mains supply voltage, and the mains electric wiring should be suitable for the oven’s power rating (also indicated on the appliance identification plate);...
- Page 5 Instruction on use Control panel features This oven combines in a single appliance the advantages of traditional convection ovens with those of modern forced air ventilation ovens. Oven programmer/timer display Digital timer Oven Function control knob Thermostat control knob Oven In Use symbol Minute Minder symbol Auto Function symbol Decimal point...
- Page 6 Instructions on use - continued Oven Functions Defrost: This function turns on the rear fan without any heating elements on. The time required to defrost the food depends on the room temperature. Lower element with fan (Pizza function): This function turns on the lower heating element and the rear fan for food that needs to cook more from the base. Conventional cooking (Bake): This function turns on the upper and lower heating elements for conventional cooking.
- Page 7 Instructions on use - continued Minute Minder When the oven is running a cooking function or just in Operating mode (the Oven In Use symbol is on), the Minute Minder function can be used. This is an alarm that can be set, but does not effect the operation of the oven in any way. Press the Mode button twice until the Minute Minder symbol (5) starts to flash.
-
Page 8: Maintenance And Cleaning
Instructions on use - continued Cooking guidelines •Please refer to the information given on food packaging for guidance on cooking temperatures and times. Once familiar with the performance of your appliance, temperatures and times can be varied to suit personal preference. If you are using the fan oven function, then you should follow the information given on the food packaging for this particular mode of cooking. -
Page 9: Maintenance
Maintenance How to keep your oven in good condition Important: Before cleaning your oven, or performing maintenance, disconnect it from the power supply. To extend the life of your oven, it must be cleaned frequently, keeping in mind that: •Do not use steam equipment to clean the appliance •The enamelled or stainless steel parts should be washed with lukewarm water without using any abrasive powders or corrosive substances which could ruin them;... -
Page 10: Troubleshooting
Troubleshooting The oven isn’t coming on. • Check that the oven is in manual operation mode. • Check that you have selected a cooking function and a cooking temperature. There appears to be no power to the oven and grill. •... -
Page 11: Pre-Installation
The following conditions apply in respect of the warranty given in this certificate: 1. Monaco Corporation Limited (“Monaco”) warrants the following Robinhood products against manufacturing defects and faulty materials, under normal use and subject to the exclusions in this certificate, for a period of: Rangehood, Ovens, Cooktops, Dishwashers - 24 months from date of original purchase for domestic use. - Page 12 The product was used outdoors. 2. All Robinhood Rangehoods are suitable for indoor use only and not suitable over BBQs or charcoal cookers designed for outdoor use. 3. In addition, this warranty does not extend to damage or defects which in our opinion, directly or indirectly arise from or are due to: exposing the product to acidic or corrosive materials or chemicals such as dyes, solvents, denture cleaner or acetone;...
