Diagram 4:
Impurities (electrode)
After cleaning, check the optimal fit of the suction dome on the
electrode housing to ensure the suction electrode functions optimally.
Instructions: Intensive Wiping Disinfection / Cleaning
1. Use only the disinfectants mentioned in Point 5.3.1.
2. Clean / disinfect all areas of the electrode, which have come into contact with the pa-
tient.
Electrode suction dome out-
side, grip area / suction area
Suction area
Diagram 6:
Suction dome cleaning
outside
Seite 24
User Guide
Diagram 5:
Check the position of the suction
dome on the electrode housing
Cleaning of the
electrode contact surface
Diagram 7:
Clean contact area (electrode)
Cleaning the inside of the elec-
trode suction dome, sealing lip,
electrode body / suction dome /
suction area
Sealing lip
Suction area
Diagram 8:
Suction dome cleaning inside
