- Page 1 suspension for suction leads height-adjustable telescopic arm internal cable feed 300° pivot range Operating Manual pump module: small, quiet, powerful suction Trolley optional (standard version w/o trolley)
- Page 2 User guide ergo vac Sales and Service Information mbnet Engineering GmbH has a network of customer service, sales and advisory centres. Contact your nearest mbnet Engineering GmbH subsidiary to obtain the address of your local distributor. You can find a full list of all subsidiaries and distributors on our website: www.mbnet.de Sales information can also be obtained from: info@mbnet.de...
-
Page 3: Table Of Contents
User guide ergo vac Table of Contents Safety Notes ..............4 Application ..............19 Responsibility of the User ..........4 Operating Conditions ........... 19 Organisational Measures ..........4 Starting a Recording ............ 19 Indications for Use ............4 Contra-indication ............4 Maintenance and Care .......... -
Page 4: Safety Notes
User Guide ergo vac Safety Notes Responsibility of the User The device must be used only by qualified physicians or trained medical professionals. The responsibilities of the staff for operating and maintaining the device must be speci- fied by the operator. -
Page 5: Safety-Conscious Operation
Danger of electric shock - do not open the device! It contains no parts, which can be repaired by the user. Servicing must only be performed by qualified technicians authorised by mbnet Engineering GmbH. Switch off the device before cleaning and disconnect it from the mains. -
Page 6: Terms Of Warranty
The warranty is void if unauthorised or unqualified persons attempt to make repairs. In case the device is defective, send it to your local mbnet Engineering GmbH representa- tive or directly to the manufacturer. The manufacturer can only be held responsible for the... -
Page 7: Symbols Used On The Device
User guide ergo vac 1.10.2 Symbols Used on the Device BF-symbol, no protection against defibrillation current. Dispose of as electronic waste. Attention: consult accompanying documents. Manufacturer Date of manufacture CE label Follow the manufacturer’s instructions Seite 7... -
Page 8: Introduction
Introduction The ergo vac is an ECG suction device for recording heart potentials during resting and stress ECGs and sending the data to the ECG device. The built-in control panel allows for easy operation and efficient configuration of the device. -
Page 9: Scope Of Delivery
User guide ergo vac 2.1.2 Scope of Delivery Standard Model Resting and stress ECGs Mains operation Options Battery operation Trolley (with grounding cable) Fixation pump module on trolley Control Box with Control Panel What makes the control box stand out is its optimal user ergonomics. It consists of a control panel, control electronics and defibrillation protection. -
Page 10: Cable Arm
User Guide ergo vac Cable Arm The special feature of the cable arm is its hidden cable routing as well as its movable and horizontal telescopic arm. height-adjustable telescopic arm Control Joint Pump Module pump module Power Power Switch Fuse... -
Page 11: Fixation Pump Module
User guide ergo vac Fixation module pump Bracket for pump module ergo vac with Trolley vexio-cart. Comment: We have a large selection of brackets (bracket can be created according to customer requirements), incl. table and wall mounts fixation pump module... -
Page 12: Operation
User Guide ergo vac Operation Getting Started Electric shock hazard. The device must not be used if it is not properly grounded or HAZARD the power cable is damaged or suspected to be damaged. Location The device must not be stored or operated in a wet, humid or dusty area. -
Page 13: Power Supply
User guide ergo vac Power Supply 3.3.1 Displays for Mains or Battery Power The unit can be connected to the mains or be supplied from the built-in battery (option). In both modes the button on the control panel will light up. -
Page 14: Suction Levels
User Guide ergo vac Suction Levels The system‘s suction lines can be individually adjusted for each patient using 5 suction levels. When the unit is turned on, it activates an average default level (about -150 mbar). The current suction level is indicated by the green LEDs on the control panel. The highest level is about -220 mbar and should only be used in extreme cases (a lot of body hair). -
Page 15: Possible Sources Of Errors With The Ecg Recording
User guide ergo vac Placement of Electrodes 1 Only use electrodes that are recommended by mbnet Engineering GmbH. 2 To increase the electrode's conductivity and adherence: Shave the areas where the electrodes are to be placed, if necessary. Thoroughly clean the areas with alcohol or soapy water (skin cream is often applied above all during the winter as this will increase electrode resistance enormously(!) –... -
Page 16: Before The Recording
User Guide ergo vac Possible Sources of Errors with the ECG Recording 5.2.3 Before the Recording Inform the patient about the procedure so that they are not frightened. The patient must: be lying down relaxed (attention: hands must be on the couch, not in the air)! not be cold (above all for resting ECG recordings)! No powerful devices must be in operation close by at the same time. -
Page 17: Resting Ecg With 10-Lead Patient Cable Electrode Placement For Standard Leads
User guide ergo vac Resting ECG with 10-lead Patient Cable Electrode Placement for Standard Leads C1 red C1 red C2 yellow C2 yellow C3 green C3 green C4 brown C4 brown C5 black C5 black C6 purple C6 purple R red... -
Page 18: Right Precordial (C4R)
User Guide ergo vac Right Precordial (C4r) The ACC/AHA guidelines recommend that in all patients with myocardial infarction with in- ferior ST elevation, an investigation into a possible RV ischemia or a RV infarction is carried out; this investigation is undertaken with a right precordial C4r recording. -
Page 19: Application
User guide ergo vac Application Do not take an ECG picture until you have read and understood the safety instructions at the Caution beginning of these instructions for use. The device is a BF type device. During ECG recording, make sure that neither the patient- nor the conductive parts of the patient connection or the electrodes (including the neutral ones) come into contact with other persons or conductive parts (even if they are grounded). -
Page 20: Maintenance And Care
User Guide ergo vac Maintenance and Care The device requires regular checks (Chapter 7.5). The test results must be recorded in writing and compared to the values in the accompanying documents. Maintenance work not described in this section may only be performed by a qualified, authorised technician. -
Page 21: Cleaning The Housing And Cables
User guide ergo vac Cleaning the Housing and Cables Switch off the device before cleaning and disconnect it from the mains. Do not, under any Warning circumstances, immerse the device in cleaning liquid and do not sterilise it with hot water, steam or air. -
Page 22: Cleaning And Storing The Electrodes
User Guide ergo vac 7.2.1 Cleaning and Storing the Electrodes NEVER use metallic or sharp items to clean the electrodes. This could damage them Caution irreparably. Make absolutely sure that the suction unit is operating in cleaning mode when you... -
Page 23: Recommended Cleaning And Disinfection Methods For Electrodes
User guide ergo vac 7.2.2 Recommended Cleaning and Disinfection Methods for Electrodes Wiping disinfection / cleaning: to be carried out after every use Intensive wiping disinfection / cleaning: 1x daily after the last use Immersion disinfection, cleaning / drying: 1x daily after the last use This cleaning method can damage the suction unit if not carried out correctly. - Page 24 User Guide ergo vac Diagram 4: Diagram 5: Impurities (electrode) Check the position of the suction dome on the electrode housing After cleaning, check the optimal fit of the suction dome on the electrode housing to ensure the suction electrode functions optimally.
- Page 25 User guide ergo vac Pull off the silicone suction dome from the electrode housing (in the direction of the arrow). Then clean the inside of the suction dome and the electrode housing. Pull off the suction dome Diagram 9: Remove the suction dome Replace the suction dome after it has been cleaned back on the electrode housing.
- Page 26 User Guide ergo vac Immersion Disinfection and Subsequent Cleaning and Drying This cleaning method can damage the suction unit if not carried out correctly. Caution 1. Switch off the suction unit. 2. Position the container for the cleaning liquid in such a way that no medical equipment can be become wet from drops of liquid.
- Page 27 User guide ergo vac Activate this function twice in a row. If the blow-out function is not activated correctly, it cannot be ruled out that cleaning liquid will flow over the electrode suction hose into the suction device. Diagram 13: Blow-out/ cleaning key 7.
-
Page 28: Cleaning The Suction Hoses
User Guide ergo vac 7.2.3 Cleaning the Suction Hoses UNDER NO CIRCUMSTANCES pull on the suction hoses during cleaning (risk of breaking the cable)! You MUST also instruct your temporary staff and the responsible cleaning staff on this matter! Do not vacuum up any water into the suction hoses with the cleaning mode 7.2.4... -
Page 29: Disinfection
User guide ergo vac Disinfection Disinfection removes certain bacteria and viruses. Please refer to the manufacturer’s infor- mation. Use commercially available disinfectants intended for clinics, hospitals and medical practices. Disinfect the device in the same way as described for cleaning the device in Chapter 5.2. -
Page 30: Battery Disposal
Remarks: Recurrent test in line with the information from the ECG manufacturer Inspection carried out by: In case of a defect, please contact the service department of your hospital, your mbnet Engineering GmbH representative or the local after-sales service: (Name) -
Page 31: Replacement Of Parts With A Limited Life, Every 3 - 5 Years
Always use mbnet Engineering GmbH spare parts and disposables or products ap- Warning proved by mbnet Engineering GmbH. Failure to do so may invalidate the warranty. Your local representative stocks all the disposables and accessories available for the handy vaq. In case of difficulty, contact our head office. Our staff will be pleased to help process your order or to provide information on all mbnet Engineering GmbH products. -
Page 32: Replacement Of Ecg Leads
Contact customer service doesn‘t work Should these tips be of no help in fixing the problem, please call your mbnet Engineering GmbH dealer or directly contact mbnet Engineering GmbH. Please have your model name and serial number ready. They are listed on the type label on the pump housing. - Page 33 User guide ergo vac Transmitter Testing max. power Distance d HF source frequency frequency P (W) Wireless (MHz) [MHz] communications devices Various radio services (TETRA 400) 380-390 Walkie-talkie (FRS) 430-470 Rescue service, police, fire brigade, servicing (GMRS) L TE band 13/17 704 –...
-
Page 34: Warranty
Always use mbnet Engineering GmbH spare parts and disposables or products approved Warning by mbnet Engineering GmbH. Failure to do so may endanger life and/or invalidate the war- ranty. Your local representative stocks all the disposables and accessories available for the de- vice. -
Page 35: Preventing Electromagnetic Interference
User guide ergo vac Patient Module 5 vacuum levels 80, 120, 160, 200, 220 mbar System Cable System cable 1.9 m ECG connection 15-channel in accordance with IEC Standard Norm Control cable 1.5 m Hose 1.5 m Electrodes Material sintered Ag/AgCI, silicone suction cup... -
Page 36: Emc Information
Guidance and manufacturer’s declaration – electromagnetic emissions The ergo vac is intended for use in the electromagnetic environment specified below. The customer or the user of the ergo vac should assure that it is used in such an environment. Compliance... -
Page 37: Table1: Immunity (All Devices Electromagnetic Emissions
Guidance and manufacturer’s declaration – electromagnetic immunity The ergo vac is intended for use in the electromagnetic environment specified below. The customer or the user of s ergo vac hould assure that it is used in such an environment. IEC 60601... -
Page 38: Table 2: Immunity: Electromagnetic Immunity
To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the ergo vac is used exceeds the applicable RF com- pliance level above, the ergo vac should be observed to verify normal operation. If abnormal performance is observed, additional measures may be necessary, such as re-orienting or relocating the ergo vac. -
Page 39: Table 3: Electromagnetic Immunity
The ergo vac is intended for use in the electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the ergo vac can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the ergo vac as recommended below, according to the maximum output power of the communication equipment. - Page 40 Declation of Conformity EC Declaration of Conformity Directive 93/42/EEC Annex VII Directive 2007/47/EEC Annex VII The manufacturer mbnet Engineering GmbH Kirschauer Strasse 37a D-02681 Callenberg hereby declares that the product ergo vac (Class I) is in compliance with the following:...
