- Page 1 300° pivot range ergo basic Operating Manual...
- Page 2 Engineering GmbH has a network of customer service, sales and advisory centres. Contact your nearest mbnet Engineering GmbH subsidiary to obtain the address of your local distributor. You can find a full list of all subsidiaries and distributors on our website: www.mbnet.de Sales information can also be obtained from: info@mbnet.de...
-
Page 3: Table Of Contents
Leads ................... 10 Warranty ................24 Fixation of cable arm............10 Accessories and Disposables ..........24 Serial Number ..............11 Supplied accessories for ergo basic ........11 Technical Data ..............25 Operation ................11 Device ................. 25 System Cable ..............25 Getting Started and Location .......... -
Page 4: Safety Notes
User Guide ergo basic Safety Notes Responsibility of the User The device must be used only by qualified physicians or trained medical professionals. The responsibilities of the staff for operating and maintaining the device must be specified by the operator. -
Page 5: Safety-Conscious Operation
Maintenance Do not open the device! It contains no parts, which can be repaired by the user. Servicing must only be performed by qualified technicians authorised by mbnet Engineering GmbH. Do not use high-temperature sterilisation processes (such as autoclaving). Do not use e-beamor gamma radiation sterilisation. -
Page 6: Terms Of Warranty
In case the device is defective, send it to your local mbnet Engineering GmbH representative or directly to the manufacturer. The manufacturer can only be held responsible for the safety, reliability and performance of... -
Page 7: Symbols Used On The Device
User Guide ergo basic 1.10.2 Symbols Used on the Device BF-symbol, no protection against defibrillation current Dispose of as electronic waste. Attention: consult accompanying documents Manufacturer Date of manufacture CE label Follow the manufacturer’s instructions Seite 7... -
Page 8: Introduction
User Guide ergo basic Introduction The ergo basic is an ECG cable for recording heart potentials during resting and stress ECGs and sending the data to the ECG device. Elements of the Suction Device 2.1.1 Overview height-adjustable telescopic arm internal cable feed 300°... -
Page 9: Patient Module
User Guide ergo basic Patient module What makes the patient module stand out is its optimal user ergonomics. The control panel is easy to clean. patient module ECG-leads Joint The joint has a locking screw. Caution The joint is set from factory! Adjust only when necessary! -
Page 10: Telescopic Arm Closure
User Guide ergo basic Cable Arm The cable arm has a special feature on a hidden cable management as well as a movable and horizontal telescopic arm. telescopic arm closure telescopic arm patient module joint Telescopic arm closure Open and close to extend and retract of the telescopic arm. -
Page 11: Serial Number
User Guide ergo basic Serial Number Supplied accessories for ergo basic Cable arm with patient module Electrode suction hose (6 x 1 m / 4 x 1.30 m) Standard bracket Operation manual Operation Getting Started DANGER The device must not be used if it is suspected to be damaged. -
Page 12: Ecg Recording
A minimal resistance between skin and electrode is required to obtain the best ECG signal and ensure the highest quality ECG recording. Therefore, please note the following points: 1 Only use electrodes that are recommended by mbnet Engineering GmbH. 2 To increase the electrode‘s conductivity and adherence: Shave the areas where the electrodes are to be placed, if necessary. -
Page 13: Possible Sources Of Errors With The Ecg Recording
User Guide ergo basic Possible Sources of Errors with the ECG Recording 4.2.1 Preparation With adhesive electrodes, observe their shelf-life - They should not beexpired! Should you use suction bulbs and clams, always check wether they are cleaned before usage. -
Page 14: Electrode Identification And Colour Code
User Guide ergo basic Electrode Identifi cation and Colour Code The electrode colour codes in this section correspond to Code 1 (IEC). Below you will find the corresponding colour codes in accordance with Code 2 (AHA). Colour Colour label label... - Page 15 User Guide ergo basic IEC label AHA label Connecting the ECG patient cable C1, red V1, red Fourth intercostal space at the right sternal border C2, yellow V2, yellow Fourth intercostal space at the left sternal border C3, green V3, green...
-
Page 16: Right Precordial (C4R)
User Guide ergo basic Right Precordial (C4r) IEC label AHA label Connecting the ECG patient cable C1, white / red V1, brown / red Fourth intercostal space at the right sternal border C2, white / yellow V2, braun / yellow... -
Page 17: Starting A Recording
User Guide ergo basic Starting a Recording 1 Preparing the patient 2 Apply electrodes 3 Ask the patient about their well-being 4 Performing a measurement 5 In case suction pulbs and extremity electrodes are applied: Clean them before next use Maintenance and Care The device requires regular checks (see page 21, Chapter 6.4). -
Page 18: Cleaning The Housing And Cables
User Guide ergo basic Cleaning the Housing and Cables Do not, under any circumstances, immerse the device in cleaning liquid and do not sterilise it with hot water, Warning steam or air. Do not autoclave the unit or any accessories. -
Page 19: Cleaning The Ecg-Leads
User Guide ergo basic 6.2.1 Cleaning the ECG-leads UNDER NO CIRCUMSTANCES pull on the ECG-leads during cleaning (risk of breaking the cable)! You MUST also instruct your temporary staff and the responsible cleaning staff on this matter! 6.2.2 Cleaning Connection Cables 1 Check the cable before cleaning for any damage. -
Page 20: Disinfection
User Guide ergo basic Disinfection Disinfection removes certain bacteria and viruses. Please refer to the manufacturer’s information. Use commercially available disinfectants intended for clinics, hospitals and medical practices. Disinfect the device in the same way as described for cleaning the device (see page 18, chapter 6.2) 6.3.1... -
Page 21: Inspection Report
Recurrent test in line with the information from the ECG manufacturer Inspection carried out by: * In case of a defect, please contact the service department of your hospital, your mbnet Engineering GmbH representative or the local after-sales service: (Name) ..........(Telephone) .......... -
Page 22: Accessories And Consumables
Check plug connection Firmly push in connecting plug Should these tips be of no help in fixing the problem, please call your mbnet Engineering GmbH dealer or directly contact mbnet Engineering GmbH. Please have your model name and serial number ready. -
Page 23: Preventing Electromagnetic Interference
User Guide ergo basic Preventing Electromagnetic Interference The user can help avoid electromagnetic disturbances by keeping the recommended minimum distance between portable and mobile HF telecommunication devices (transmitters) and the unit. The distance depends on the output performance of the communication device as indicated in the table below. -
Page 24: Warranty
Always use mbnet Engineering GmbH spare parts and disposables or products approved Warning by mbnet Engineering GmbH. Failure to do so may endanger life and/or invalidate the warranty. Your local representative stocks all the disposables and accessories available for the device. -
Page 25: Technical Data
User Guide ergo basic Technical Data 8.1. Device Ambient conditions Operating temperature 10 to 50 °C, storage 10 to 40 °C Relative humidity Air 30 to 75 % (non-condensing) Pressure during use 700 to 1060 hPa System Cable System cable length 2.1 m... - Page 26 Directive 2007/47/EEC Annex VII The manufacturer mbnet Engineering GmbH Kirschauer Straße 37a OT Callenberg D-02681 Callenberg hereby declares that the product ergo basic (Class I) is in compliance with the following: Directive 93/42/EEC Directive 2007/47/EEC Applied Standards IEC 60601-1 Manuel Bucher Callenberg, 12.06.2020...
- Page 27 User Guide ergo basic Seite 27...
