2.6 Fixation module pump
Bracket for pump module ergo vac with Trolley vexio-cart.
Comment: We have a large selection of brackets (bracket can be
created according to customer requirements), incl. table and wall
mounts
2.7

Serial Number

cable arm
2.8 Supplied accessories for ergo vac (mains) or (battery)
Cable arm with patient module
Electrode suction hose (6 x 1.30 m / 4 x 1.50 m)
Spacers (2 pcs with 3 rows / 2 pcs with 2 rows)
Pump unit, large
Power cable for mains connection
ECG Spray 250 ml
Standard bracket
Screw set consisting of:
2 x cable ties 200mm
1 x D-sub connection kit
1 x cable clip, small
1 x 5 mm and 1 x 2.5 mm Allen key
4 x each of M6x12 / M6x16 / M6x20 Allen screw
4 x each of M6 nut / M6 self-locking / M6 square nut
4 x 6.3 washer / 4 x 6.37 spring washer / 4 x rubber feet
Operation manual
User guide
fixation
pump module
pump module
ergo vac
pump module
with accumulator
