This data pack provides detailed installation, configuration and operation information for
the 7910 HD Upconverter and Cross Converter module as part of the Avenue Signal
Integration System.
The module information in this data pack is organized into the following sections:
• Module Overview
• Applications
• Installation
• Cabling
• Module Configuration and Control
Front Panel Controls and Indicators
°
Avenue PC Remote Control
°
Avenue Touch Screen Remote Control
°
• Troubleshooting
• Software Updating
• Warranty and Factory Service
• Specifications
Model 7910
Data Pack
G
N
S
Revision 2.4 SW v2.3.3
7910-1
